Is the Allen-Bradley 1734-IB8S new or used?

We offer the 1734-IB8S in multiple conditions, from unused surplus to professionally reconditioned units. Every option is sourced and verified independently and covered by our 2-year replacement warranty.

What are the key ratings of the 1734-IB8S?

The 1734-IB8S runs on 24 Volts DC (nom).

What is the Allen-Bradley 1734-IB8S?

The 1734-IB8S is an Allen-Bradley Point I/O Guard I/O Safety Module.

UPC	10612598350619
Brand	Allen-Bradley
Series	POINT I/O
Weight	2.2 ounces
Dimensions	3.03 x 0.98 x 2.17 (inches)
Input Type	Current Sinking
Module Type	Guard I/O Safety Module
Output Type	Current Sourcing
Manufacturer	Rockwell Automation
Enclosure Type	Open
Available Series	A and B
Number of Inputs	Eight (8) Inputs
Power Dissipation	3.4 Watts
Part Number/Catalog No.	1734-IB8S
Operating Supply Voltage	24 Volts DC (nom)
No. of Pulse Test Outputs	Four (4) Pulse Test Outputs

Allen-Bradley

1734-IB8S

Rate this product

Ready to ShipPLCs Point I/O

The Allen-Bradley 1734-IB8S is a POINT I/O Guard I/O Safety Module with eight current sinking inputs and four pulse test outputs, designed for open enclosures. Operating at 24V DC, it measures 3.03" x 0.98" x 2.17" and weighs 2.2 ounces, ensuring efficient power dissipation at 3.4 Watts.

PDF

We currently only collect tax from customers in the state of North Carolina. If you are exempt on your purchase, please email your Sales Tax & Use Exemption Form to sales@replacenc.com.
If you are checking out via a quote we send you, there is an option to upload your form at the time of purchase.

If you have already placed an order, please send us your form and we can refund the charged taxes.

Overview of Allen-Bradley 1734-IB8S

The Allen-Bradley 1734-IB8S is a digital input module that is part of the POINT I/O series. As a safety-rated component, it is designed to reliably collect and convey binary input signals from various types of safety devices such as emergency stops, safety curtains, and interlock switches to a safety controller. The module operates as an integral part of a comprehensive safety system, ensuring that machinery operates safely and within compliances.

Technical Features of the 1734-IB8S

The 1734-IB8S module is equipped with eight inputs, which are safety-rated for up to Category 4/PL e according to ISO 13849-1 and SIL 3 as per IEC 62061. It has a voltage range of 19.2 to 31.2 VDC and is compatible with the POINT I/O system, which allows for flexibility and efficiency in system configuration. The module also supports the CIP Safety protocol over EtherNet/IP for seamless integration into a networked safety system.

Installation and Configuration Aspects

Installation of the 1734-IB8S is streamlined through its modular design, enabling easy mounting on a DIN rail and hassle-free connection to other POINT I/O modules. It is also designed for efficient setup, with rotary switches available for setting the network address without the need for software. The user-friendly design reduces installation time and simplifies maintenance processes.

Safety Functionality

The primary role of the Allen-Bradley 1734-IB8S module is to ensure a high level of safety. It is adept at performing critical safety functions, with diagnostic capabilities that support swift recognition and resolution of system issues. This diagnostic information can be retrieved by a safety controller, promoting proactive system management and minimizing potential downtime resulting from safety-related incidents.

Applications of the 1734-IB8S

The 1734-IB8S module is versatile and is commonly utilized in various industries where machine safety is paramount. These include automotive, manufacturing, and material handling sectors. The safety inputs of the module are suitable for connections with light curtains, safety mats, emergency stops, and door switches, which are vital components in the protection of personnel and equipment on the production floor.
