Is the Allen-Bradley 1756-IF8 new or used?

We offer the 1756-IF8 in multiple conditions, from unused surplus to professionally reconditioned units. Every option is sourced and verified independently and covered by our 2-year replacement warranty.

What are the key ratings of the 1756-IF8?

The 1756-IF8 is rated at 1.73 Watts.

What is the Allen-Bradley 1756-IF8?

The 1756-IF8 is an Allen-Bradley ControlLogix 1756 Analog Input Module.

UPC	10612598171795
Brand	Allen-Bradley
Inputs	2 high-speed differential, 4 differential, 8 single-ended
Series	ControlLogix
UNSPSC	32151705
Module Type	Analog Input Module
Manufacturer	Rockwell Automation
Input Resolution	(+--) 10.25 Volts, 0-5.125 Volts, 0-10.25 Volts
Power Consumption	1.73 Watts
RSLogix 5000 Software	Verson 8.02.00 or later
Part Number/Catalog No.	1756-IF8
Power Dissipation (Max)	1.73 Watts (Voltage), 2.33 Watts (Current)
Backplane Current (5Volts)	150 milliamps
Removeable Terminal Blocks	1756-TBCH, 1756-TBS6H
Backplane Current (24Volts)	40 milliamps

Allen-Bradley

1756-IF8

Rate this product

Ready to ShipPLCs ControlLogix 1756

The Allen-Bradley 1756-IF8 is a ControlLogix Analog Input Module designed for versatile data acquisition, supporting 2 high-speed differential, 4 differential, and 8 single-ended inputs with a high input resolution. It consumes a maximum of 1.73 watts, with removable terminal blocks, and is compatible with RSLogix 5000 software version 8.02.00 or later.

PDF

We currently only collect tax from customers in the state of North Carolina. If you are exempt on your purchase, please email your Sales Tax & Use Exemption Form to sales@replacenc.com.
If you are checking out via a quote we send you, there is an option to upload your form at the time of purchase.

If you have already placed an order, please send us your form and we can refund the charged taxes.

Allen-Bradley 1756-IF8 Analog Input Module

The Allen-Bradley 1751-IF8 is an analog input module that falls within the ControlLogix product family. This module is designed to help users interface with a wide range of analog signals, making it an essential component for applications requiring precise monitoring and control of process variables. The 1756-IF8 is capable of handling eight differential analog inputs and provides high levels of accuracy and resolution.

Key Features of the 1756-IF8

The 1756-IF8 module supports a variety of input signal types including voltage and current signals. It offers different input ranges to accommodate various industrial needs. With 16 bits of resolution, it ensures that accurate data is captured for the control system to interpret. Additionally, the module includes on-board data alarming, scaling to engineering units, and real-time channel sampling to assist in detailed process monitoring and analysis.

Flexibility and Compatibility

Designed for versatility, the Allen-Bradley 1756-IF8 integrates seamlessly with other modules in the ControlLogix platform. It is compatible with a wide range of input devices such as sensors and transducers, enabling users to customize their systems according to specific requirements. The module's backward compatibility with older ControlLogix chassis and power supplies ensures that it can be integrated into existing systems with minimal disruption.

Programming and Diagnostics

Users can program the Allen-Bradley 1756-IF8 module using the Studio 5000 Logix Designer application, which provides a user-friendly interface for configuration and diagnostics. The module supports electronic keying to prevent incorrect module replacement and provides comprehensive diagnostics for fault detection and troubleshooting. This helps to minimize downtime and ensures consistent and reliable operation of the control system.

Construction and Certification

The Allen-Bradley 1756-IF8 is built to withstand harsh industrial environments. It has a solid construction and complies with multiple international standards, including cUL-us, CE, and Ex certification. Its robust design guarantees dependable performance even under extreme conditions, such as high temperatures, vibrations, and electrical noise, which are common in industrial settings.
