| Brand | Allen-Bradley |
| Series | ControlLogix |
| Outputs | 16-Points |
| Voltage | 120-140 Volts AC |
| Enclosure | None |
| Module Type | AC Output Module |
| Manufacturer | Rockwell Automation |
| Isolation Voltage | 50 Volts Continuous |
| Operating Voltage Range | 74-265 Volts AC |
| Part Number/Catalog No. | 1756-OA16K |
| Power Dissipation (Max) | 6.5 Watts at 60 degrees Celsius |
| Backplane Current at 5 Volts | 400 milliamps |
| Removeable Terminal Block(s) | 1756-TBNH, 1756-TBSH |
| Maximum Output Current Rating-Point | 0.5 Amps at 60 degrees Celsius |
| Maximum Output Current Rating-Module | 4 Amps at 60 degrees Celsius |
Does the Allen-Bradley 1756-OA16K come with a warranty?
Yes. The 1756-OA16K is backed by our 24-Month Replace Industrial Warranty, with no rush fees or hidden warranty charges. If a unit fails under normal use within the warranty period, we repair or replace it.
Is this 1756-OA16K a genuine Allen-Bradley part?
The 1756-OA16K is sourced and verified independently. Replace Industrial, LLC is not a Rockwell Automation Authorized Distributor, and all warranties are provided directly by Replace Industrial.
Is the Allen-Bradley 1756-OA16K new or used?
We offer the 1756-OA16K in multiple conditions, from unused surplus to professionally reconditioned units. Every option is sourced and verified independently and covered by our 2-year replacement warranty.
What are the key ratings of the 1756-OA16K?
The 1756-OA16K runs on 74-265 Volts AC and draws 0.5 Amps at 60 degrees Celsius.
What is the Allen-Bradley 1756-OA16K?
The 1756-OA16K is an Allen-Bradley ControlLogix 1756 AC Output Module.
1756-OA16K
The Allen-Bradley 1756-OA16K from Rockwell Automation is a ControlLogix AC Output Module featuring 16 points with a voltage range of 120-140V AC. It delivers up to 0.5A per point and 4A per module at 60°C, with maximum power dissipation of 6.5W and 400mA backplane current at 5V. Compatible with 1756-TBNH/TBSH terminal blocks and offers a continuous isolation voltage of 50V.
