| UPC | 10612598171474 |
| Brand | Allen-Bradley |
| Series | ControlLogix |
| UNSPSC | 32151705 |
| Outputs | 8-Point Individually Isolated |
| Enclosure | None |
| Module Type | Isolated Relay Output Module |
| Manufacturer | Industrial Automation |
| Contact Output | Form C contacts |
| Output Current | 2, 0.5, 0.25 Amps |
| Mean Bounce Time | 1.2 ms |
| Isolation Voltage | 250V (continuous), basic insulation type, outputs-to- backplane, and output-to-output |
| Operating Voltage | 10-265 Volts AC, 5-150 Volts DC |
| Expected contact life | 300 kHz resistive; 100 kHz inductive |
| Part Number/Catalog No. | 1756-OX8I |
| Power Dissipation (Max) | 3.1 Watts at 60 Celsius |
| Maximum Output Delay Time | 13 milliseconds |
| Initial Contact Resistance | 100 m? @ 6V 1 A |
| Maximum Switching frequency | 1 operation/3 s (0.3 Hz at rated load) |
| Backplane Current at 5 Volts | 100 mA |
| Removeable Terminal Block(s) | 1756-TBCH, 1756-TBS6H |
Does the Allen-Bradley 1756-OX8I come with a warranty?
Yes. The 1756-OX8I is backed by our 24-Month Replace Industrial Warranty, with no rush fees or hidden warranty charges. If a unit fails under normal use within the warranty period, we repair or replace it.
Is this 1756-OX8I a genuine Allen-Bradley part?
The 1756-OX8I is sourced and verified independently. Replace Industrial, LLC is not a Rockwell Automation Authorized Distributor, and all warranties are provided directly by Replace Industrial.
Is the Allen-Bradley 1756-OX8I new or used?
We offer the 1756-OX8I in multiple conditions, from unused surplus to professionally reconditioned units. Every option is sourced and verified independently and covered by our 2-year replacement warranty.
What are the key ratings of the 1756-OX8I?
The 1756-OX8I draws 2, 0.5, 0.25 Amps and runs on 10-265 Volts AC, 5-150 Volts DC.
What is the Allen-Bradley 1756-OX8I?
The 1756-OX8I is an Allen-Bradley ControlLogix 1756 Isolated Relay Output Module.
1756-OX8I
The Allen-Bradley 1756-OX8I is an 8-point isolated relay output module from the ControlLogix series, accommodating various contact outputs at 10-265V AC and 5-150V DC. Its versatility is defined by its range of output current options, high isolation voltage, and robust performance metrics, including extended contact life and minimal bounce time. Designed for industrial automation, it ensures reliable interfacing and switching frequency in demanding environments.
