| UPC | 10662468992807 |
| Brand | Allen-Bradley |
| Series | A and B |
| UNSPSC | 32151705 |
| Software | RSLogix5000 |
| Dimension | 118 x 35 x 87 mm (4.65 x 1.38 x 3.43 in.) Height with mounting tabs 138 mm (5.43 in.)Current Draw @ 5.14Vdc: 425 mA |
| Wire size | (22…14 AWG) solid or (22…16 AWG) |
| Wire type | Cu-90 °C (194 °F) |
| Input Type | Analog Input |
| Slot width | 1 |
| Module Type | 16 Channel Input Module |
| Manufacturer | Industrial Automation /Allen-Bradley |
| Product Line | CompactLogix |
| Product Type | Discrete Input Module |
| Input Voltage | 100/120 VAC |
| No. of Inputs | 16 |
| Enclosure Type | Open |
| Input Frequency | 47 - 63 Hz |
| Input delay, On | 20 ms |
| Shipping Weight | 2 pounds |
| Heat Dissipation | 3.3 W |
| Voltage Category | 100 to 102 Volts AC |
| Backplane Current | 1.4 Amps at 24 Volts |
| Operating Voltage | 79 to 132V AC |
| Power Consumption | 33.6 Watts |
| Power Dissipation | 7.5 Watts |
| Communication Cable | 16 Point |
| Shipping Dimensions | 8x8x5 inches |
| Current Draw @ 5.1Vdc | 115 mA |
| On state voltage, min | 79 VAC |
| Compatible Controllers | MicroLogix 1500; 1769 CompactLogix |
| Off state voltage, max | 20 VAC |
| Part Number/Catalog No. | 1769-IA16 |
Does the Allen-Bradley 1769-IA16 come with a warranty?
Yes. The 1769-IA16 is backed by our 24-Month Replace Industrial Warranty, with no rush fees or hidden warranty charges. If a unit fails under normal use within the warranty period, we repair or replace it.
Is this 1769-IA16 a genuine Allen-Bradley part?
The 1769-IA16 is sourced and verified independently. Replace Industrial, LLC is not a Rockwell Automation Authorized Distributor, and all warranties are provided directly by Replace Industrial.
Is the Allen-Bradley 1769-IA16 new or used?
We offer the 1769-IA16 in multiple conditions, from unused surplus to professionally reconditioned units. Every option is sourced and verified independently and covered by our 2-year replacement warranty.
What are the key ratings of the 1769-IA16?
The 1769-IA16 runs on 100/120 VAC, is rated at 33.6 Watts, and draws 115 mA.
What is the Allen-Bradley 1769-IA16?
The 1769-IA16 is an Allen-Bradley CompactLogix 1769 16 Channel Input Module.
1769-IA16
The Allen-Bradley 1769-IA16 is a CompactLogix 16-channel analog input module for MicroLogix 1500 systems, operating at 79 to 132V AC with a 20 ms input delay. It requires a 1.4 Amp current at 24 Volts from the backplane and features a slot width for easy integration.
