| Product type | Variable speed drive |
| Manufacturer | Schneider Electric |
| Product line | Altivar |
| Series | ATV320 |
| Part number | ATV320D15N4B |
| Rated power | 15 kW |
| Output power | 20 HP |
| Supply voltage | 380 to 500 VAC |
| Supply frequency | 50/60 Hz |
| Supply configuration | Three-phase |
| Maximum input current at 380 VAC | 47.3 A |
| Maximum input current at 500 VAC | 33.3 A |
| Apparent power | 28.8 kVA |
| Maximum inrush current | 36.7 A |
| Nominal current | 33.0 A |
| Maximum transient current | 49.5 A |
| Output voltage | 0 to 500 VAC |
| Frequency range | 0.1 to 599 Hz |
| Control method | Vector control and V/F control |
| Mounting type | Book-style panel mount |
| Protection rating | IP20 |
| Cooling system | Forced air cooling |
| EAN | 3606480931321 |
What is the ATV320D15N4B?
The ATV320D15N4B is a Schneider Electric Altivar Machine ATV320 variable speed drive designed for controlling three-phase asynchronous and synchronous motors in complex machinery.
What power and supply ratings does it have?
It has a rated motor power of 15 kW (20 HP), accepts a three-phase 380–500 VAC supply, and provides an output voltage range of 0–500 VAC.
What operating frequency range is supported?
The drive supports a frequency range of 0.1–599 Hz.
Which motor-control methods are available?
The ATV320D15N4B supports both vector control and V/F control for motor operation.
How is the drive mounted and protected?
It uses a compact book-style panel-mount or wall-mount design, has an IP20 protection rating, and uses forced-air cooling.
What communication options are available?
The drive supports Modbus serial and CANopen communication, with option modules available for CANopen, EtherCAT, Profibus DP V1, PROFINET, Ethernet Powerlink, EtherNet/IP, and DeviceNet.
Does the ATV320D15N4B include an EMC filter?
Yes. It includes an integrated Class C3 EMC filter.
Does the Schneider Electric ATV320D15N4B come with a warranty?
Yes. The ATV320D15N4B is backed by our 24-Month Replace Industrial Warranty, with no rush fees or hidden warranty charges. If a unit fails under normal use within the warranty period, we repair or replace it.
Is this ATV320D15N4B a genuine Schneider Electric part?
The ATV320D15N4B is sourced and verified independently. Replace Industrial is not an authorized distributor, affiliate, or representative of Schneider Electric, and all warranties are provided directly by Replace Industrial.
Is the Schneider Electric ATV320D15N4B new or used?
We offer the ATV320D15N4B in multiple conditions, from unused surplus to professionally reconditioned units. Every option is sourced and verified independently and covered by our 2-year replacement warranty.
What are the key ratings of the ATV320D15N4B?
The ATV320D15N4B is rated at 15 kW, runs on 380 to 500 VAC, and draws 47.3 A.
What is the Schneider Electric ATV320D15N4B?
The ATV320D15N4B is a Schneider Electric ATV 320 Variable speed drive.
ATV320D15N4B
The ATV320D15N4B is a standard-version Altivar Machine ATV320 variable speed drive for complex machines. It provides 15 kW rated power on a three-phase 380–500 V AC supply, with 0–500 V AC output, 32 A current rating, and a 0.1–599 Hz operating range. Its book-format, wall-mount design, IP20 protection, forced-air cooling, and vector or V/F control support flexible industrial motor control.
