| Product type | Spindle drive unit |
| Power rating | 22 kW |
| Motor lead wire size | 2 mm² (AWG 14) |
| Maximum motor wiring length | 30 m |
| Ambient temperature | 40°C max |
What is the MDS-D-SPJ3-22NA?
The MDS-D-SPJ3-22NA is a model in the Mitsubishi MDS-D-SVJ3/SPJ3 spindle drive series. The supplied product information identifies it as a 22 kW spindle drive unit.
What spindle motor output ratings are listed for the MDS-D-SPJ3 series?
The manual lists standard spindle motor combinations for MDS-D(*)-SP(#)-240 at 18.5 kW and 22 kW, and for MDS-D(*)-SP(#)-320 at 22 kW, 26 kW, and 30 kW. The applicable unit may depend on the motor power-constant range.
Can the MDS-D-SPJ3-22NA use semi-closed or full-closed loop control?
The manual lists motor-type settings for the MDS-D-SVJ3/SPJ3 series: 2200 for semi-closed loop control, 4200 for full-closed loop control using a spindle-side ABZ pulse output detector, and 6200 for full-closed loop control using a spindle-side serial output detector.
Is the second-speed detection setting available for MDS-D-SPJ3?
No. The manual states that the SP030 second-speed detection setting is not available for the MDS-D-SPJ3 series.
What speed range is specified for the second-speed detection setting?
The manual specifies a setting range of 10 to 1000 r/min for the second-speed detection value.
Does the Mitsubishi MDS-D-SPJ3-22NA come with a warranty?
Yes. The MDS-D-SPJ3-22NA is backed by our 24-Month Replace Industrial Warranty, with no rush fees or hidden warranty charges. If a unit fails under normal use within the warranty period, we repair or replace it.
Is this MDS-D-SPJ3-22NA a genuine Mitsubishi part?
The MDS-D-SPJ3-22NA is sourced and verified independently. Replace Industrial is not an authorized distributor, affiliate, or representative of Mitsubishi, and all warranties are provided directly by Replace Industrial.
Is the Mitsubishi MDS-D-SPJ3-22NA new or used?
We offer the MDS-D-SPJ3-22NA in multiple conditions, from unused surplus to professionally reconditioned units. Every option is sourced and verified independently and covered by our 2-year replacement warranty.
What are the key ratings of the MDS-D-SPJ3-22NA?
The MDS-D-SPJ3-22NA is rated at 22 kW and operates across 40°C max.
What is the Mitsubishi MDS-D-SPJ3-22NA?
The MDS-D-SPJ3-22NA is a Mitsubishi MELDAS Spindle drive unit.
MDS-D-SPJ3-22NA
MDS-D-SPJ3-22NA is a spindle drive unit in the Mitsubishi MDS-D-SVJ3/SPJ3 series. It is designed for use with applicable spindle motors; compatibility depends on the motor power-constant range and should be confirmed with Mitsubishi.
All products are covered by our 2-Year (24-Month) Replace Industrial Warranty. If a unit is found defective under normal use within the warranty period, we repair or replace it at no additional cost, and a unit may be returned for a full refund within 30 days if returned in the same condition it was sent.
Replace Industrial is an independent distributor and does not convey the manufacturer's warranty; all warranties are provided by Replace Industrial alone. Read the full warranty policy
