Manufacturer	Schneider Electric
Product Type	Analog Output Module
Product Line	Modicon Quantum
Number of Channels	8
Output Range	6-30 VDC
Maximum Current	550 mA
Update Time	5 ms
Setting Time	3.2 ms to ±0.1% of final value
Isolation Between Channels and Bus	1780 V for 1 minute AC
Power Dissipation	5 W
External Power Supply	6-30 VDC
Operating Temperature	0°C to +60°C
LED Indicators	Yes
Weight	2.00 lbs (0.91 kg)
Marking	CE

What is the part number 140ACO13000?

The 140ACO13000 is an 8-channel analog output module manufactured by Schneider Electric for the Modicon Quantum series.

What is the output voltage range of the 140ACO13000?

The module features an output range of 6-30 VDC.

What is the maximum current capacity of this module?

The 140ACO13000 has a maximum current capacity of 550 mA.

What is the isolation rating between channels and the bus?

The module provides 1780 V AC isolation between channels and the bus for a duration of 1 minute.

What is the operating temperature range for the 140ACO13000?

The module supports an operating temperature range of 0°C to +60°C.

What is the update time and setting time for the 140ACO13000?

The module has an update time of 5 ms and a setting time of 3.2 ms to ±0.1% of the final value.

Does the 140ACO13000 require an external power supply?

Yes, the module requires an external power supply within the 6-30 VDC range.

What is the power dissipation of the 140ACO13000?

The power dissipation for this module is 5 W.

Is the 140ACO13000 currently in production?

According to reference data, the 140ACO13000 is discontinued by the manufacturer, with the BMXAMO0802 listed as a recommended replacement.

Does the Schneider Electric 140ACO13000 come with a warranty?

Yes. The 140ACO13000 is backed by our 24-Month Replace Industrial Warranty, with no rush fees or hidden warranty charges. If a unit fails under normal use within the warranty period, we repair or replace it.

Is this 140ACO13000 a genuine Schneider Electric part?

The 140ACO13000 is sourced and verified independently. Replace Industrial is not an authorized distributor, affiliate, or representative of Schneider Electric, and all warranties are provided directly by Replace Industrial.

Is the Schneider Electric 140ACO13000 new or used?

We offer the 140ACO13000 in multiple conditions, from unused surplus to professionally reconditioned units. Every option is sourced and verified independently and covered by our 2-year replacement warranty.

What are the key ratings of the 140ACO13000?

The 140ACO13000 operates across 0°C to +60°C.

What is the Schneider Electric 140ACO13000?

The 140ACO13000 is a Schneider Electric Modicon Quantum Analog Output Module.

Schneider Electric

140ACO13000

Rate this product

Ready to ShipPLCs Modicon Quantum

The Schneider Electric 140ACO13000 is an 8-channel analog output module for the Modicon Quantum series, featuring a 6-30 VDC output range, 550 mA maximum current, and 1780 V AC isolation between channels and the bus. It supports an operating temperature range of 0°C to +60°C and includes LED indicators for status monitoring.

PDF

We currently only collect tax from customers in the state of North Carolina. If you are exempt on your purchase, please email your Sales Tax & Use Exemption Form to sales@replacenc.com.
If you are checking out via a quote we send you, there is an option to upload your form at the time of purchase.

If you have already placed an order, please send us your form and we can refund the charged taxes.

Overview of Schneider Electric 140ACO13000

The Schneider Electric 140ACO13000 is an 8-channel analog output module designed for the Modicon Quantum series. This unit is engineered to manage multiple signals efficiently within industrial control systems, providing reliable analog output capabilities for various applications.

Designed for robust performance, the module operates within a temperature range of 0°C to +60°C and features extensive isolation capabilities to enhance safety and prevent interference in complex environments.

Key Features

This module includes eight individual output channels, allowing for the efficient management of multiple analog signals. It features LED indicators for easy status monitoring and requires an external power supply within the 6-30 VDC range for optimal performance.

The unit is marked with CE certification and is designed with a fault type of Open Circuit (4-20 mA). It offers a maximum current capacity of 550 mA, meeting high-performance standards often required in intricate control systems.

Performance and Capacity

The 140ACO13000 provides an output range of 6-30 VDC and a maximum current of 550 mA. It features a power dissipation of 5 W, ensuring efficient energy usage while maintaining high-quality analog outputs.

In terms of responsiveness, the module records an update time of 5 ms and a setting time of 3.2 ms to ±0.1% of the final value. It provides isolation between channels and the bus of 1780 V for 1 minute AC, enhancing safety and preventing potential interference.

Installation and Compatibility

The module is designed for the Modicon Quantum series and requires an external power supply of 6-30 VDC. It is suitable for installation in environments with operating temperatures ranging from 0°C to +60°C.

For replacement purposes, the reference material identifies BMXAMO0802 as a recommended substitute. The module weighs approximately 2.00 lbs (0.91 kg) according to one source, though another source lists it at 1.00 lbs.

Applications and Industries

The Schneider Electric 140ACO13000 is suitable for various industrial applications that require reliable analog output management. Its robust isolation and high-performance standards make it appropriate for intricate control systems in diverse industrial settings.

Designed for reliability and efficiency, this module is engineered to deliver high-quality analog outputs in environments where precise signal management and safety are critical.
