Manufacturer	Schneider Electric
Product Type	Analog Input Module
Product Line	Modicon Quantum
Part Number	140ARI03010
UPC	785901792222
Weight	2.00 lbs (0.91 kg)
Bus Current Requirement	200 mA
Analog Input Channels	8
Power Dissipation	1 W
Input Type	Differential
Module Format	Standard
Input Impedance	10 MOhm
Input Resolution	13 Bits
Frequency Range	47/63 Hz
Addressing Requirement	9 input words

What type of module is the 140ARI03010?

The 140ARI03010 is an analog input module from the Schneider Electric Modicon Quantum product line.

How many input channels does the 140ARI03010 provide?

The module provides 8 differential analog input channels.

What is the input resolution of the 140ARI03010?

The module operates with an input resolution of 13 bits.

What is the input impedance of the 140ARI03010?

The input impedance is rated at 10 MOhm.

What are the power requirements for the 140ARI03010?

The module requires a bus current of 200 mA and has a power dissipation of 1 W.

What is the addressing requirement for the 140ARI03010?

The module requires 9 input words for addressing.

What is the weight of the 140ARI03010?

The module weighs 2.00 lbs (0.91 kg).

Is the 140ARI03010 currently in production?

The module is discontinued by the manufacturer.

Does the Schneider Electric 140ARI03010 come with a warranty?

Yes. The 140ARI03010 is backed by our 24-Month Replace Industrial Warranty, with no rush fees or hidden warranty charges. If a unit fails under normal use within the warranty period, we repair or replace it.

Is this 140ARI03010 a genuine Schneider Electric part?

The 140ARI03010 is sourced and verified independently. Replace Industrial is not an authorized distributor, affiliate, or representative of Schneider Electric, and all warranties are provided directly by Replace Industrial.

Is the Schneider Electric 140ARI03010 new or used?

We offer the 140ARI03010 in multiple conditions, from unused surplus to professionally reconditioned units. Every option is sourced and verified independently and covered by our 2-year replacement warranty.

What is the Schneider Electric 140ARI03010?

The 140ARI03010 is a Schneider Electric Modicon Quantum Analog Input Module.

How fast does the 140ARI03010 ship?

In-stock orders for the 140ARI03010 ship the same day when placed before our daily cutoff. Expedited and same-day air options are available if you are facing downtime, with no rush fees. Our team is based in Raleigh, North Carolina.

Schneider Electric

140ARI03010

Rate this product

PLCs Modicon Quantum

The 140ARI03010 is a Modicon Quantum analogue input module, specifically designed for precise temperature sensing with 8 input channels for Ni/Pt sensors (100, 200, 500, 1000 Ohm ranges), enhancing the Quantum automation platform's capability for process control applications.

PDF

We currently only collect tax from customers in the state of North Carolina. If you are exempt on your purchase, please email your Sales Tax & Use Exemption Form to sales@replacenc.com.
If you are checking out via a quote we send you, there is an option to upload your form at the time of purchase.

If you have already placed an order, please send us your form and we can refund the charged taxes.

Overview of Schneider Electric 140ARI03010

The 140ARI03010 is an analog input module from the Schneider Electric Modicon Quantum series, designed for precise data acquisition in industrial automation systems. This module provides eight channels of differential analog inputs, enabling the collection of high-fidelity signals for complex control processes.

Engineered for straightforward integration into existing setups, the 140ARI03010 features a standard module format. It is a critical component for enhancing the capabilities of the Quantum automation platform in process control applications.

Key Features

This module offers 13-bit input resolution, ensuring accurate measurement capabilities for intricate control tasks. The input impedance is rated at 10 MOhm, which helps minimize signal loss and maintains high fidelity in measurements.

The 140ARI03010 utilizes a differential input type, which is beneficial for reducing noise in industrial environments. It requires a bus current of 200 mA and has a low power dissipation rating of 1 W, contributing to efficient energy use while maintaining robust performance.

Performance and Capacity

The module supports eight separate analog input channels, allowing for versatile data collection across multiple sensors. It is designed to operate within a frequency range of 47 Hz to 63 Hz, fitting well within standard industrial power frequency applications.

For system integration, the 140ARI03010 has an addressing requirement of 9 input words, streamlining communication protocols. The unit weighs approximately 0.91 kg (2.00 lbs), making it a compact yet effective addition to control racks.

Installation and Compatibility

Designed with a standard module format, the 140ARI03010 is intended for straightforward integration into existing Modicon Quantum systems. Its compact physical dimensions and standard form factor facilitate easy installation in industrial control cabinets.

The module is part of the Modicon Quantum product line, ensuring compatibility with the broader Schneider Electric automation ecosystem. Users should note that this part has been discontinued by the manufacturer, so availability may be limited to existing stock or replacement units.

Applications and Industries

The 140ARI03010 is suitable for various automation applications that require precise analog data acquisition. Its differential input capability and high resolution make it ideal for process control systems where signal integrity is paramount.

This module is commonly used in industrial environments where reliable data collection is necessary for intricate control processes. It supports the automation needs of sectors requiring robust and efficient analog input handling within the Modicon Quantum platform.
