| Manufacturer | Schneider Electric |
| Product Line | Modicon Quantum |
| Part Number | 140DAM59000 |
| EAN | 3595861126954 |
| Weight | 1.31 lbs (0.60 kg) |
| Series | I/O Modules |
| Module Type | Discrete I/O module |
| Discrete Inputs | 16 inputs |
| Discrete Outputs | 8 solid-state outputs |
| Nominal Voltage | 115 V AC |
| Typical Voltage Limit | Up to 132 V AC |
| Output Load Current | ≤ 8 A per module |
| Voltage Drop | 1.5V |
| Total Discrete I/O Channels | 24 channels |
| Mounting | Backplane/rack mounting |
| Input Response Time (1 to 0) | 7.3 to 12.3 ms |
| Input Response Time (0 to 1) | 4.9 to 0.75 ms |
| Voltage Limit for 10 Seconds | Up to 156 VAC |
| Voltage Limit Within One Cycle | Up to 200 VAC |
| Output Current per Point | 2 A |
| Input Current | 5 mA |
| Power Consumption | 5.5 W |
| Operating Temperature | 0 to +60 °C |
What is the 140DAM59000?
The 140DAM59000 is a Schneider Electric Modicon Quantum discrete I/O module with 16 discrete inputs and 8 solid-state outputs.
What is the nominal input voltage?
The module has a nominal input voltage of 115 V AC.
What voltage limits does the 140DAM59000 support?
The reference lists typical voltage limits up to 132 V AC, up to 156 VAC for 10 seconds, and up to 200 VAC within one cycle.
What are the output load ratings?
The reference lists a maximum output load of 8 A per module and per group, and 4 A per output point.
What are the input response times?
Input response time is 7.3 to 12.3 ms for a state 1-to-0 transition and 0.75 to 4.9 ms for a state 0-to-1 transition.
How many discrete I/O channels does the module provide?
The module provides 24 discrete I/O channels in total.
How is the 140DAM59000 mounted?
The module supports backplane or rack mounting.
What is the listed operating temperature range?
The reference lists an operating temperature range of 0 to +60°C.
Does the Schneider Electric 140DAM59000 come with a warranty?
Yes. The 140DAM59000 is backed by our 24-Month Replace Industrial Warranty, with no rush fees or hidden warranty charges. If a unit fails under normal use within the warranty period, we repair or replace it.
Is this 140DAM59000 a genuine Schneider Electric part?
The 140DAM59000 is sourced and verified independently. Replace Industrial is not an authorized distributor, affiliate, or representative of Schneider Electric, and all warranties are provided directly by Replace Industrial.
Is the Schneider Electric 140DAM59000 new or used?
We offer the 140DAM59000 in multiple conditions, from unused surplus to professionally reconditioned units. Every option is sourced and verified independently and covered by our 2-year replacement warranty.
What are the key ratings of the 140DAM59000?
The 140DAM59000 runs on 115 V AC, draws 2 A, and is rated at 5.5 W.
What is the Schneider Electric 140DAM59000?
The 140DAM59000 is a Schneider Electric Modicon Quantum Discrete I/O module.
140DAM59000
The 140DAM59000 is a mixed discrete I/O module for the Modicon Quantum automation platform, featuring 16 inputs at 115 V AC and 8 solid-state outputs. Designed to streamline complex industrial processes, this component enhances system flexibility and control for robust automation applications.
