Is the Allen-Bradley 1734-FPD new or used?

We offer the 1734-FPD in multiple conditions, from unused surplus to professionally reconditioned units. Every option is sourced and verified independently and covered by our 2-year replacement warranty.

What is the Allen-Bradley 1734-FPD?

The 1734-FPD is an Allen-Bradley Point I/O Field Power Distributor.

How fast does the 1734-FPD ship?

In-stock orders for the 1734-FPD ship the same day when placed before our daily cutoff. Expedited and same-day air options are available if you are facing downtime, with no rush fees. Our team is based in Raleigh, North Carolina.

UPC	10612598206886
Brand	Allen-Bradley
Series	POINT I/O
Module Type	Field Power Distributor
Manufacturer	Rockwell Automation
Isolation Voltage	250 Volts Continuous
Power Supply Input	12/24 Volts DC or 120/240 Volts AC
Part Number/Catalog No.	1734-FPD
Field Power Supply Current	10 amps

Allen-Bradley

1734-FPD

Rate this product

Ready to ShipPLCs Point I/O

The Allen-Bradley 1734-FPD is a POINT I/O Field Power Distributor by Rockwell Automation designed to handle 12/24V DC or 120/240V AC input with a robust field power supply current of 10 amps. It ensures reliable isolation up to 250 volts continuous, ideal for diverse power distribution needs in complex systems.

PDF

We currently only collect tax from customers in the state of North Carolina. If you are exempt on your purchase, please email your Sales Tax & Use Exemption Form to sales@replacenc.com.
If you are checking out via a quote we send you, there is an option to upload your form at the time of purchase.

If you have already placed an order, please send us your form and we can refund the charged taxes.

Overview of the Allen-Bradley 1734-FPD

The Allen-Bradley 1734-FPD is a Field Potential Distributor module that belongs to the POINT I/O family. It is designed to work within a distributed control system, extending the backplane power to additional POINT I/O modules. This device helps in maintaining the voltage levels that are necessary for the proper functioning of the system, especially when a large number of modules are connected, and the distance from the power supply increases.

Functionality of the 1734-FPD

The main function of the 1734-FPD is to distribute field power to I/O modules. It separates the field power from the backplane power, which helps in managing the electrical power distribution better and protects the I/O modules. It also provides indicators for field power and system health, contributing to the overall maintainability and diagnostics of the system.

Installation and Configuration

Installation of the 1734-FPD is straightforward, as it can be easily snapped onto the DIN rail alongside other POINT I/O modules. The configuration of the 1734-FPD requires proper setting of the field power jumper depending on whether the field power is sourced from the system or an external supply. It is critical to follow the manufacturer's instructions to avoid any configuration errors which can lead to system malfunction.

Technical Specifications

The Allen-Bradley 1734-FPD operates with a nominal input voltage of 24V DC, and it supports a wide range of POINT I/O modules. It provides a means to extend the voltage required to power the modules connected downstream. The device can also be used to isolate the power to specific sections of the I/O bank for added flexibility and safety in system design.

Applications and Industries

The 1734-FPD module finds its application in various industries including manufacturing, automotive, and material handling. It is suitable for use where a reliable and extendable power distribution system is required for efficient control and operation. Its robust design assures continuous and stable performance, which is crucial for industrial environments with demanding operational conditions.
