Is the Allen-Bradley 1734-IA4 new or used?

We offer the 1734-IA4 in multiple conditions, from unused surplus to professionally reconditioned units. Every option is sourced and verified independently and covered by our 2-year replacement warranty.

What are the key ratings of the 1734-IA4?

The 1734-IA4 runs on 120 Volts AC and carries None (open-style) protection.

What is the Allen-Bradley 1734-IA4?

The 1734-IA4 is an Allen-Bradley Point I/O Digital AC Input Module.

Brand	Allen-Bradley
Inputs	2 or 1 group of 4
Series	POINT I/O
Weight	30.9 g (1.09 oz)
Dimensions	2.21 x 0.47 x 2.97 inches
Module Type	Digital AC Input Module
Manufacturer	Rockwell Automation
Input Voltage	120 Volts AC
Type of Inputs	Non-isolated, Sinking
Enclosure Rating	None (open-style)
Number of Inputs	4
POINTBus Current	75 milliamps
Power Dissipation	0.1 Watts Maximum
Thermal Dissipation	3.4 BTU Maximum
Part Number/Catalog No.	1734-IA4

Allen-Bradley

1734-IA4

Rate this product

Ready to ShipPLCs Point I/O

The Allen-Bradley 1734-IA4 is a POINT I/O digital AC input module designed by Rockwell Automation. It has four non-isolated, sinking inputs that accept a 120V AC input voltage. This compact and lightweight module, measuring just 2.21 x 0.47 x 2.97 inches and weighing 30.9 grams, is built for open-style enclosures and consumes minimal power, only 0.1 watts, with a thermal dissipation of 3.4 BTU maximum.

PDF

We currently only collect tax from customers in the state of North Carolina. If you are exempt on your purchase, please email your Sales Tax & Use Exemption Form to sales@replacenc.com.
If you are checking out via a quote we send you, there is an option to upload your form at the time of purchase.

If you have already placed an order, please send us your form and we can refund the charged taxes.

Overview of Allen-Bradley 1734-IA4

The Allen-Bradley 1734-IA4 is a digital input module designed for use within automation systems. It is part of the POINT I/O product family and is utilized primarily in industrial environments. The module is engineered to facilitate the integration of digital input signals into a control system, such as a PLC (Programmable Logic Controller).

Technical Specifications

The 1734-IA4 module is equipped with four input points, with each point capable of handling a voltage range typically between 10-30VDC. This module's architecture allows for easy installation and removal, providing great flexibility for system design and maintenance. Due to its compatibility with the POINT I/O series, the 1734-IA4 benefits from the series' modular design, which helps to reduce downtime and enables quick changes and upgrades to the system.

Installation and Wiring

Installation of the Allen-Bradley 1734-IA4 module is streamlined with the use of a POINT I/O base, onto which the module can be snapped. The terminal base houses the I/O terminals and carries the necessary backplane connectivity. This module also supports POINT Guard safety functions when installed in appropriate safety-rated systems. Proper wiring and grounding are critical for ensuring reliable operation and safety compliance.

Communication and Compatibility

The Allen-Bradley 1734-IA4 module communicates with a control system via the POINT I/O communication interface. This interface allows for robust and efficient communication between I/O modules and the control system. The module is compatible with various Allen-Bradley PLCs, making it a flexible choice for many industrial applications. Additionally, it supports various communication protocols, such as EtherNet/IP, depending on the setup of the POINT I/O system.

Application Areas

Common applications for the Allen-Bradley 1734-IA4 include manufacturing automation, material handling, and process control, among others. Its reliable input monitoring capabilities make it suitable for safety systems, operational control, and data acquisition within a diverse range of industries. As an integral part of a larger control system, this module helps ensure that automation processes are both efficient and accurate.
