| UPC | 10662468640883 |
| Brand | Allen-Bradley |
| Series | SLC 500 |
| Weight | 2.5 pounds (1.1 kilograms( |
| Location | 1746 Chassis |
| Frequency | 47 to 63 Hertz |
| Dimensions | 5.5 x 3.3x 5.7 inches |
| Input Power | 75 or 50 Watts |
| Module Type | Power Supply |
| Manufacturer | Rockwell Automation |
| Input Voltage | 10...30V dc |
| Inrush Current | 20 A (required for turn-on) |
| Fuse Protection | 1746-F1 or equivalent |
| CPU Hold up time | 20 ms (full load) 3000 ms (no load) |
| Input Voltage Range | 10-30 Volts DC |
| Programming Software | RSLogix 500 |
| Operating Temperature | 0 to 60 Celsius |
| Part Number/Catalog No. | 1746-P7 |
| Internal Current Capacity | 12V dc input: 2.0 A at 5V dc 0.46 A at 24V dc; 24V dc input: 3.6 A at 5V dc 0.87 A at 24V dc |
| Backplane Current (24 Volts) | 0.46 Amps |
| CPU Hold up time, 24VDC input | 24V dc input: 40 ms at 0V dc (full load) 1860 ms at 0V dc (no load) 790 ms at 11V dc (full load) continuous at 11V dc (no load) |
| CPU Hold up time, 12 VDC input | 12V dc input: 1.37 ms at 0V dc (full load) 895 ms at 0V dc (no load) 10 ms at 9V dc (full load) continuous at 9V dc (no load) |
| Typical line power requirement | 12V dc input: 50VA; 24V dc input: 75VA |
Does the Allen-Bradley 1746-P7 come with a warranty?
Yes. The 1746-P7 is backed by our 24-Month Replace Industrial Warranty, with no rush fees or hidden warranty charges. If a unit fails under normal use within the warranty period, we repair or replace it.
Is this 1746-P7 a genuine Allen-Bradley part?
The 1746-P7 is sourced and verified independently. Replace Industrial, LLC is not a Rockwell Automation Authorized Distributor, and all warranties are provided directly by Replace Industrial.
Is the Allen-Bradley 1746-P7 new or used?
We offer the 1746-P7 in multiple conditions, from unused surplus to professionally reconditioned units. Every option is sourced and verified independently and covered by our 2-year replacement warranty.
What are the key ratings of the 1746-P7?
The 1746-P7 runs on 10...30V dc and operates across 0 to 60 Celsius.
What is the Allen-Bradley 1746-P7?
The 1746-P7 is an Allen-Bradley SLC 500 Power Supply.
1746-P7
The Allen-Bradley 1746-P7 is a reliable SLC 500 series power supply module from Rockwell Automation. Designed for a 1746 chassis, it operates within a 10-30V DC input voltage range, has an internal current capacity up to 3.6A at 5V DC, and provides a steady power output with a 20ms CPU hold-up time at full load.
