Is the Allen-Bradley 1747-BA new or used?

We offer the 1747-BA in multiple conditions, from unused surplus to professionally reconditioned units. Every option is sourced and verified independently and covered by our 2-year replacement warranty.

What are the key ratings of the 1747-BA?

The 1747-BA operates across 0-60 Celsius.

What is the Allen-Bradley 1747-BA?

The 1747-BA is part of the Allen-Bradley SLC 500 line.

Brand	Allen-Bradley
Cable	Belden 9463
Series	SLC 500
Weight	0.37 pounds (168 grams)
Voltage	3 Volts
Function	Battery
Connectors	6-Pin Phoenix Connector
Dimensions	5.72 x 1.37 x 5.15 inches
Battery Type	Lithium
Manufacturer	Rockwell Automation
Operating Temperature	0-60 Celsius
Part Number/Catalog No.	1747-BA
Backplane Current (5 Volts DC)	375 milliamps

Allen-Bradley

1747-BA

Rate this product

PLCs SLC 500

The Rockwell Automation Allen-Bradley 1747-BA is a lithium battery designed for the SLC 500 series, providing 3 volts of power and supporting a 0-60 Celsius operating temperature. Weighing 0.37 pounds with dimensions of 5.72 x 1.37 x 5.15 inches, it includes a Belden 9463 cable and a 6-pin Phoenix connector.

PDF

We currently only collect tax from customers in the state of North Carolina. If you are exempt on your purchase, please email your Sales Tax & Use Exemption Form to sales@replacenc.com.
If you are checking out via a quote we send you, there is an option to upload your form at the time of purchase.

If you have already placed an order, please send us your form and we can refund the charged taxes.

Introduction to Allen-Bradley 1747-BA Battery

The Allen-Bradley 1747-BA is a lithium battery that is designed to be used in a range of industrial automation hardware. Specifically, it's commonly used as a backup battery for Allen-Bradley's Programmable Logic Controllers (PLCs), including the SLC 500 series. Its primary function is to preserve the memory of the PLC when external power is lost, ensuring that programs and data are not erased during power outages.

Specifications of the 1747-BA Battery

The 1747-BA battery is a 3-Volt Lithium non-rechargeable battery. It features a capacity of 1000mAh, which guarantees a reliable power supply for the PLC memory over long periods of time. The standard size of the battery is small, which allows it to fit seamlessly within the PLC housing. Its operating temperature range is typically between -30°C and +80°C, making it suitable for harsh industrial environments.

Installation and Usage

To maintain the integrity of the PLC's memory, it is crucial to properly install the 1747-BA battery. The battery is typically installed in a designated compartment within the PLC, and it should be replaced every few years or as indicated by the system's low battery warning. Caution must be used during installation to ensure correct polarity and secure fit within the compartment to avoid damage to the PLC or the battery itself.

Important Considerations

When handling the Allen-Bradley 1747-BA battery, it is essential to be aware of the safety and disposal requirements due to its lithium content. Used batteries must be disposed of in accordance with local environmental regulations. Additionally, as a critical component ensuring the reliability of industrial automation systems, using genuine Allen-Bradley replacement batteries is recommended to prevent potential compatibility and performance issues.
