| Brand | Allen-Bradley |
| Series | ControlLogix |
| Outputs | 16-Point Electronically Fused |
| Voltage | 12-24 Volts DC |
| Enclosure | None |
| Module Type | Electronic Fused DC Output Module |
| Manufacturer | Rockwell Automation |
| Isolation Voltage | 50 Volts Continuous |
| Operating Voltage Range | 10-30 Volts DC |
| Part Number/Catalog No. | 1756-OB16EK |
| Power Dissipation (Max) | 4.1 Watts at 60 degree Celsius |
| Backplane Current at 5 Volts | 250 milliamps |
| Removeable Terminal Block(s) | 1756-TBNH, 1756-TBSH |
| Maximum Output Current Rating-Point | 1 Amp at 60 Celsius |
| Maximum Output Current Rating-Module | 8 Amps at 60 degrees Celsius |
Does the Allen-Bradley 1756-OB16EK come with a warranty?
Yes. The 1756-OB16EK is backed by our 24-Month Replace Industrial Warranty, with no rush fees or hidden warranty charges. If a unit fails under normal use within the warranty period, we repair or replace it.
Is this 1756-OB16EK a genuine Allen-Bradley part?
The 1756-OB16EK is sourced and verified independently. Replace Industrial, LLC is not a Rockwell Automation Authorized Distributor, and all warranties are provided directly by Replace Industrial.
Is the Allen-Bradley 1756-OB16EK new or used?
We offer the 1756-OB16EK in multiple conditions, from unused surplus to professionally reconditioned units. Every option is sourced and verified independently and covered by our 2-year replacement warranty.
What are the key ratings of the 1756-OB16EK?
The 1756-OB16EK runs on 10-30 Volts DC and draws 1 Amp at 60 Celsius.
What is the Allen-Bradley 1756-OB16EK?
The 1756-OB16EK is an Allen-Bradley ControlLogix 1756 Electronic Fused DC Output Module.
1756-OB16EK
The Allen-Bradley 1756-OB16EK is a 16-point electronically fused DC output module from Rockwell Automation's ControlLogix series, handling 12-24V DC with a 10-30V operating range. Each point supports up to 1A output at 60°C, with the module maxing at 8A. It features a 1756-TBNH/TBSH removable terminal block and 50V continuous isolation.
