| UPC | 10612598171450 |
| Brand | Allen-Bradley |
| Series | ControlLogix |
| Outputs | 8-Point |
| Voltage | 240 Volts AC |
| Enclosure | None |
| Module Type | Output Module |
| Manufacturer | Rockwell Automation |
| Isolation Voltage | 50 Volts Continuous |
| Operating Voltage Range | 10-30 Volts AC |
| Part Number/Catalog No. | 1756-ON8 |
| Power Dissipation (Max) | 5.1 Watts at 60 degrees Celsius |
| Backplane Current at 5 Volts | 200 milliamps |
| Removeable Terminal Block(s) | 1756-TBNH, 1756-TBSH |
| Maximum Output Current Rating-Point | 2 Amps at 60 degrees Celsius |
| Maximum Output Current Rating-Module | 5 Amps at 30 degrees Celsius, 4 Amps at 60 degrees Celsius |
Does the Allen-Bradley 1756-ON8 come with a warranty?
Yes. The 1756-ON8 is backed by our 24-Month Replace Industrial Warranty, with no rush fees or hidden warranty charges. If a unit fails under normal use within the warranty period, we repair or replace it.
Is this 1756-ON8 a genuine Allen-Bradley part?
The 1756-ON8 is sourced and verified independently. Replace Industrial, LLC is not a Rockwell Automation Authorized Distributor, and all warranties are provided directly by Replace Industrial.
Is the Allen-Bradley 1756-ON8 new or used?
We offer the 1756-ON8 in multiple conditions, from unused surplus to professionally reconditioned units. Every option is sourced and verified independently and covered by our 2-year replacement warranty.
What are the key ratings of the 1756-ON8?
The 1756-ON8 runs on 10-30 Volts AC and draws 2 Amps at 60 degrees Celsius.
What is the Allen-Bradley 1756-ON8?
The 1756-ON8 is an Allen-Bradley ControlLogix 1756 Output Module.
1756-ON8
The Allen-Bradley 1756-ON8 is a ControlLogix output module by Rockwell Automation featuring 8 points, 240V AC, supporting up to 2A output per point. It has a removable terminal block for easy wiring and provides a 50V continuous isolation voltage, catering to robust industrial automation needs.
