| UPC | 10612598171832 |
| Pins | 36-Pin Connection |
| Brand | Allen-Bradley |
| Series | ControlLogix |
| Weight | 0.3 pounds (0.1 kilograms) |
| Enclosure | None |
| Wire Size | 20 AWG |
| Wire Type | Solid or Stranded Wire |
| Clamp Type | Screw-Clamp |
| Dimensions | 5.51 x 4.41 x 5.71 inches |
| Module Type | Terminal Block |
| Manufacturer | Rockwell Automation |
| Screw Torque | 0.5 Nm (4.4 lb/in) |
| Recommended Tool | Screwdriver |
| Screwdriver width | 3.2 mm (1/8 in.) |
| Max. Wire Insulation | 90 °C (194 °F) or greater, 1.2 mm (3/64 in.) |
| Operating Temperature | 32-140 Fahrenheit (0-60 Celsius) |
| Double wire connection | 0.33 to 1.3 mm. sq. (22…16 AWG) |
| Single Wire Connection | 0.33 to 2.1 mm. sq. (22…14 AWG) |
| Part Number/Catalog No. | 1756-TBCH |
| Power Dissipation (Max) | 6.19 Watts |
| Backplane Current (5Volts) | 1,200 milliamps |
| Backplane Current (24 Volts) | 2.5 milliamps |
Does the Allen-Bradley 1756-TBCH come with a warranty?
Yes. The 1756-TBCH is backed by our 24-Month Replace Industrial Warranty, with no rush fees or hidden warranty charges. If a unit fails under normal use within the warranty period, we repair or replace it.
Is this 1756-TBCH a genuine Allen-Bradley part?
The 1756-TBCH is sourced and verified independently. Replace Industrial, LLC is not a Rockwell Automation Authorized Distributor, and all warranties are provided directly by Replace Industrial.
Is the Allen-Bradley 1756-TBCH new or used?
We offer the 1756-TBCH in multiple conditions, from unused surplus to professionally reconditioned units. Every option is sourced and verified independently and covered by our 2-year replacement warranty.
What are the key ratings of the 1756-TBCH?
The 1756-TBCH operates across 32-140 Fahrenheit (0-60 Celsius).
What is the Allen-Bradley 1756-TBCH?
The 1756-TBCH is an Allen-Bradley ControlLogix 1756 Terminal Block.
1756-TBCH
The Allen-Bradley 1756-TBCH is a ControlLogix screw-clamp terminal block by Rockwell Automation, supporting 36-pin connections for solid or stranded wires up to 14 AWG. It operates at temperatures from 32 to 140°F, designed for easy installation with a recommended screwdriver width of 3.2mm and weighing just 0.3 pounds.
