| Pins | 20-Pin Connection |
| Brand | Allen-Bradley |
| Series | ControlLogix |
| Weight | 0.3 pounds (0.1 kilograms) |
| Enclosure | None |
| Wire Size | 20 AWG |
| Clamp Type | Spring-Clamp |
| Dimensions | 5.51 x 4.41 x 5.71 inches |
| Slot Width | 1 |
| Technology | Global Positioning System (GPS) |
| Module Type | Time Synchronization Module |
| Manufacturer | Rockwell Automation |
| Isolation voltage | 30V (continuous), Basic Insulation TypeType tested at 1000V AC for 60 s• Ethernet Ports to Backplane• IRIG-B to Backplane |
| Status Indicators | PPS, SYNCH, OK |
| Enclosure type rating | None (Open) |
| Operating Temperature | 32-140 Fahrenheit (0-60 Celsius) |
| Configuration Software | RSLogix 5000; Studio 5000 Logix Designer |
| Part Number/Catalog No. | 1756-TIME |
| Power Dissipation (Max) | 6.19 Watts |
| Auxilliary Software Tools | BOOTP-DHCP; ControlFlash |
| Backplane Current (5Volts) | 1,200 milliamps |
| Voltage and Current Rating | Backplane: 1.01A @ 5.1V DC, 2.64 mA @ 1.2 V DC |
| Backplane Current (24 Volts) | 2.5 milliamps |
| Built-in communication ports | Ethernet, IRIG-B and Antenna |
Does the Allen-Bradley 1756-TIME come with a warranty?
Yes. The 1756-TIME is backed by our 24-Month Replace Industrial Warranty, with no rush fees or hidden warranty charges. If a unit fails under normal use within the warranty period, we repair or replace it.
Is this 1756-TIME a genuine Allen-Bradley part?
The 1756-TIME is sourced and verified independently. Replace Industrial, LLC is not a Rockwell Automation Authorized Distributor, and all warranties are provided directly by Replace Industrial.
Is the Allen-Bradley 1756-TIME new or used?
We offer the 1756-TIME in multiple conditions, from unused surplus to professionally reconditioned units. Every option is sourced and verified independently and covered by our 2-year replacement warranty.
What are the key ratings of the 1756-TIME?
The 1756-TIME operates across 32-140 Fahrenheit (0-60 Celsius) and draws Backplane: 1.01A @ 5.1V DC, 2.64 mA @ 1.2 V DC.
What is the Allen-Bradley 1756-TIME?
The 1756-TIME is an Allen-Bradley ControlLogix 1756 Time Synchronization Module.
1756-TIME
The Allen-Bradley 1756-TIME ControlLogix by Rockwell Automation is a precision time synchronization module that ensures accurate timekeeping in industrial control systems. With a 20-pin connection and robust features like Ethernet and IRIG-B ports for communication, this module utilizes GPS technology. Compatible with RSLogix 5000 and Studio 5000 software, it is essential for synchronized operations in complex automation tasks.
