| Brand | Allen-Bradley |
| Series | MicroLogix 1500 |
| Features | Monochrome Display Screen |
| Function | Data Access Tool |
| Dimensions | 27 x 17 x 7 millimeters |
| Manufacturer | Rockwell Automation |
| Power supply | MicroLogix Bus |
| Input Voltage | 24 Volts DC |
| Output Source | Relay Port and DC FET |
| Supported CPU | 1764-LSP; 1764-LRP |
| Certifications | C-Tick, GOST_R, MARINE-ABS, MARINE-BVS, MARINE-DNV, MARINE-GL, MARINE-KRS, MARINE-LR, and ROSTECHNADZOR |
| Bus Current Draw | 350 MA |
| Heat Dissipation | 1.75 Watts |
| Integrated buttons | Two (2) function keys, F1 and F2, Escape, Enter, Up and down buttons |
| Allowable Functions | Direct access to 48 bit elements; Direct access to 48 integer elements; Display of controller faults |
| Removal Under Power | Supported |
| Operating Temperature | 0-55 deg.C |
| Max Expanded I/O Count | 512 |
| Part Number/Catalog No. | 1764-DAT |
| Product Lifecycle Status* | Discontinued/Obsolete |
Does the Allen-Bradley 1764-DAT come with a warranty?
Yes. The 1764-DAT is backed by our 24-Month Replace Industrial Warranty, with no rush fees or hidden warranty charges. If a unit fails under normal use within the warranty period, we repair or replace it.
Is this 1764-DAT a genuine Allen-Bradley part?
The 1764-DAT is sourced and verified independently. Replace Industrial, LLC is not a Rockwell Automation Authorized Distributor, and all warranties are provided directly by Replace Industrial.
Is the Allen-Bradley 1764-DAT new or used?
We offer the 1764-DAT in multiple conditions, from unused surplus to professionally reconditioned units. Every option is sourced and verified independently and covered by our 2-year replacement warranty.
What are the key ratings of the 1764-DAT?
The 1764-DAT runs on 24 Volts DC, draws 350 MA, and operates across 0-55 deg.C.
What is the Allen-Bradley 1764-DAT?
The 1764-DAT is part of the Allen-Bradley MicroLogix 1500 line.
1764-DAT
The Allen-Bradley MicroLogix 1500 1764-DAT, by Rockwell Automation, is a compact Data Access Tool featuring a monochrome display and integrated function keys. It supports a max of 512 I/O with 24V DC power input. Designed for direct element access and fault display, it is now obsolete but permitted removal under power within 0-55°C operational temperatures.
