Manufacturer	Rockwell Automation (Allen-Bradley)
Product Line	1791 Block I/O
Part Number	1791-24B8
UPC	612598124794
Weight	1.02 kg (2.25 lbs)
Voltage	24 VDC
Inputs per Block	24
Input On-state Voltage Range	10 to 30 VDC
Input On-state Current	11 mA at 30 V max
Input Off-state Voltage	5 VDC max
Input Off-state Current	1.5 mA min
Outputs per Block	8
Output Voltage Range	10 to 30 VDC
External Power	19.2 to 30 VDC
Product Lifecycle Status	Discontinued/Obsolete
Dimensions	176.5 mm x 68.8 mm x 98 mm (6.95 in x 2.7 in x 3.85 in)
Operating Temperature	0 to 60 °C (32 to 140 °F)
Relative Humidity	5 to 95% non-condensing
Input Signal Delay	1 ms ON, 5 ms OFF (fast); 1 ms ON, 18 ms OFF (slow)
Output Current Rating	500 mA/1 A at 30 to 60 °C (vertical); 250 to 500 mA at 30 to 60 °C (horizontal)
Output Surge Current	3 A for 50 seconds, recurring after 2 seconds
Output Off-state Current	1 mA at 1 V drop; 0.5 mA leakage
External Power Current	300 mA
Thermal Dissipation	58.1 BTU/hour
Power Dissipation	17.1 W
Mounting	DIN rail mount

What are the input and output specifications for the Allen-Bradley 1791-24B8?

The 1791-24B8 is a 24V DC block I/O module featuring 24 inputs (organized in 3 groups of 8) and 8 outputs. The input on-state voltage range is 10 to 30 VDC, with an on-state current of 11 mA at 30 VDC max. The output voltage range is also 10 to 30 VDC.

What external power supply is required for the 1791-24B8?

The module requires an external power supply providing 19.2 to 30 VDC. The internal power supply has a current rating of 300 mA.

What are the physical dimensions and weight of the 1791-24B8?

The module measures 6.95 x 4.35 x 3.85 inches (176.5 x 68.8 x 98 mm). Weight specifications vary by source, with one listing 2.00 lbs (0.91 kg) and another listing 1.70 lbs.

What is the current lifecycle status of the 1791-24B8?

The 1791-24B8 is discontinued/obsolete by the manufacturer. It is no longer in active production, which may impact long-term availability and support.

What are the operating temperature and humidity limits for this module?

The 1791-24B8 operates at temperatures between 0 and 60 degrees Celsius (32 to 140 degrees Fahrenheit) with a relative humidity of 5 to 95% non-condensing.

What are the input signal delay times for the 1791-24B8?

The input signal delay is 1 millisecond ON and 5 milliseconds OFF in fast mode, or 1 millisecond ON and 18 milliseconds OFF in slow mode.

Does the Allen-Bradley 1791-24B8 come with a warranty?

Yes. The 1791-24B8 is backed by our 24-Month Replace Industrial Warranty, with no rush fees or hidden warranty charges. If a unit fails under normal use within the warranty period, we repair or replace it.

Is this 1791-24B8 a genuine Allen-Bradley part?

The 1791-24B8 is sourced and verified independently. Replace Industrial, LLC is not a Rockwell Automation Authorized Distributor, and all warranties are provided directly by Replace Industrial.

Is the Allen-Bradley 1791-24B8 new or used?

We offer the 1791-24B8 in multiple conditions, from unused surplus to professionally reconditioned units. Every option is sourced and verified independently and covered by our 2-year replacement warranty.

What are the key ratings of the 1791-24B8?

The 1791-24B8 operates across 0 to 60 °C (32 to 140 °F) and draws 500 mA/1 A at 30 to 60 °C (vertical); 250 to 500 mA at 30 to 60 °C (horizontal).

What is the Allen-Bradley 1791-24B8?

The 1791-24B8 is part of the Allen-Bradley Block I/O line.
