| UPC | 10612598180599 |
| Brand | Allen-Bradley |
| Voltage | 24 V DC |
| Mounting | DIN Rail |
| Vibration | IEC 60068-2-6 (Test Fc, Operating) IEC 60068-2-6 (Test Fc, Operating): 5 g @ 10…500 Hz |
| Indicators | Comm A: red/grn Comm B: red/grn I/O status- red/grn |
| Current Draw | 450mA max. |
| Manufacturer | Rockwell Automation |
| Product Type | Redundant Media ControlNet Adapter |
| Inrush Current | 23A for 2ms |
| Operating Shock | IEC 60068-2-27 (Test Ea, Unpackaged Shock): 30 g |
| ControlNet cable | 3.31 mm2 (12 AWG) stranded max 1.2 mm (3/64 in.), insulation, max |
| Isolation Voltage | 850V DC |
| Power Consumption | 400mA maximum from external 24V supply |
| Power Dissipation | 3.4W maximum @ 19.2V dc |
| Communication Port | Two (2) ControlNet BNC |
| Communication Rate | 5M bps |
| ControlNet Protocol | V 1.25 |
| Data Transfer speed | 5 Mbps |
| Input Voltage Range | 19.2-31.2V DC |
| Product Description | Redundant ControlNet Adapter Module |
| Thermal Dissipation | 15.7 BTU/hr @ 19.2V dc |
| Programming software | RSLogix5, RSLogix500, RSLogix5000, Studio 5000 Logix Designer |
| Operating Temperature | -20…55 °C -4…131 °F) |
| Flexbus Output Current | 640 mA max. |
| Part Number/Catalog No. | 1794-ACNR15 |
| Surrounding Temperature | 55 °C (131 °F) |
Does the Allen-Bradley 1794-ACNR15 come with a warranty?
Yes. The 1794-ACNR15 is backed by our 24-Month Replace Industrial Warranty, with no rush fees or hidden warranty charges. If a unit fails under normal use within the warranty period, we repair or replace it.
Is this 1794-ACNR15 a genuine Allen-Bradley part?
The 1794-ACNR15 is sourced and verified independently. Replace Industrial, LLC is not a Rockwell Automation Authorized Distributor, and all warranties are provided directly by Replace Industrial.
Is the Allen-Bradley 1794-ACNR15 new or used?
We offer the 1794-ACNR15 in multiple conditions, from unused surplus to professionally reconditioned units. Every option is sourced and verified independently and covered by our 2-year replacement warranty.
What are the key ratings of the 1794-ACNR15?
The 1794-ACNR15 draws 450mA max., is rated at 400mA maximum from external 24V supply, and communicates over V 1.25.
What is the Allen-Bradley 1794-ACNR15?
The 1794-ACNR15 is an Allen-Bradley Flex I/O 1794 Redundant Media ControlNet Adapter.
1794-ACNR15
The Rockwell Automation 1794-ACNR15 is an Allen-Bradley Redundant ControlNet Adapter Module designed for reliable industrial network communication. Supporting RSLogix software suites, it offers a 5 Mbps data transfer rate, dual ControlNet ports, LED indicators, and operates at a 24V DC input voltage range within harsh 55°C environments.
