| UPC | 10612598350145 |
| Brand | Allen-Bradley |
| Mounting | DIN Rail |
| Vibration | Tested 5 g @ 10-500Hz per IEC 68-2-6 |
| Wire Size | 0.34…2.5 mm2 (22…12 AWG) stranded copper wire rated at 75 °C (167 °F) or higher, 1.2 mm (3/64 in.) insulation max |
| Indicators | Mod Status; Network Status; Link1 Status; Link2 Status |
| I/O Capacity | 8 Modules |
| Manufacturer | Rockwell Automation |
| Product Type | Flex I/O Dual Port Ethernet/IP Adapter Module |
| Ethernet cable | RJ45 Cat.5 |
| Inrush Current | 18 Amps for 2 milliseconds |
| Flexbus Current | 640 mA at 5 Volts DC maximum |
| Operating Shock | 30 g peak acceleration, 11(+1)ms pulse width |
| Isolation Voltage | 50 Volts Continuous |
| Power Consumption | 500 mA 400 mA @ 24V DC |
| Power Dissipation | 6.1 W @ 19.2V DC |
| Communication Port | Two (2) RJ45 |
| Communication Rate | 10/100 Mbps |
| Supported Protocol | Ethernet I/P |
| Data Transfer speed | 10 to 100 Mbps |
| Product Description | Redundant Ethernet Adapter Module |
| Storage Temperature | -40 to 85 C (-40 to 185 F) |
| Thermal Dissipation | 20.8 BTU/hr @ 24V DC |
| Programming software | RSLogix5, RSLogix500, RSLogix5000, Studio 5000 Logix Designer |
| Supported topologies | Linear |
| Enclosure Type Rating | None (open-style) |
| Input Voltage nominal | 24 Volts DC |
| Operating Temperature | 0 to 55 C (32 to 131 F) |
| Part Number/Catalog No. | 1794-AENTR |
| Input Voltage Range nom. | 19.2 to 31.2 Volts DC |
Does the Allen-Bradley 1794-AENTR come with a warranty?
Yes. The 1794-AENTR is backed by our 24-Month Replace Industrial Warranty, with no rush fees or hidden warranty charges. If a unit fails under normal use within the warranty period, we repair or replace it.
Is this 1794-AENTR a genuine Allen-Bradley part?
The 1794-AENTR is sourced and verified independently. Replace Industrial, LLC is not a Rockwell Automation Authorized Distributor, and all warranties are provided directly by Replace Industrial.
Is the Allen-Bradley 1794-AENTR new or used?
We offer the 1794-AENTR in multiple conditions, from unused surplus to professionally reconditioned units. Every option is sourced and verified independently and covered by our 2-year replacement warranty.
What are the key ratings of the 1794-AENTR?
The 1794-AENTR is rated at 500 mA 400 mA @ 24V DC, communicates over Ethernet I/P, and runs on 24 Volts DC.
What is the Allen-Bradley 1794-AENTR?
The 1794-AENTR is an Allen-Bradley Flex I/O 1794 Flex I/O Dual Port Ethernet/IP Adapter Module.
1794-AENTR
The Allen-Bradley 1794-AENTR is a Flex I/O Dual Port Ethernet/IP Adapter Module by Rockwell Automation, designed to facilitate robust network communication with a data transfer speed of 10/100 Mbps. It features redundant Ethernet interfaces and supports up to 8 I/O modules, ensuring high-speed Ethernet communications and system reliability.
