| UPC | 10612598137852 |
| Brand | Allen-Bradley |
| Outputs | 16 Sourcing Current |
| Manufacturer | Rockwell Automation |
| Product Type | Flex I/O Digital DC Output Module |
| Flexbus Current | 80mA @ 5V DC |
| Isolation Voltage | 50V Continuous |
| Power Dissipation | 5.3W @ 31.2V DC max. |
| Thermal Dissipation | 18.1 BTU/hr. @ 31.2V DC max. |
| On-state Current max. | 500mA per Channel |
| On-state Voltage nom. | 24V DC |
| Output Current Rating | 8.0A |
| Part Number/Catalog No. | 1794-OB16 |
| On-state Voltage Drop max. | 0.5V DC |
| Off-state Leakage Current max. | 0.5mA |
Does the Allen-Bradley 1794-OB16 come with a warranty?
Yes. The 1794-OB16 is backed by our 24-Month Replace Industrial Warranty, with no rush fees or hidden warranty charges. If a unit fails under normal use within the warranty period, we repair or replace it.
Is this 1794-OB16 a genuine Allen-Bradley part?
The 1794-OB16 is sourced and verified independently. Replace Industrial, LLC is not a Rockwell Automation Authorized Distributor, and all warranties are provided directly by Replace Industrial.
Is the Allen-Bradley 1794-OB16 new or used?
We offer the 1794-OB16 in multiple conditions, from unused surplus to professionally reconditioned units. Every option is sourced and verified independently and covered by our 2-year replacement warranty.
What are the key ratings of the 1794-OB16?
The 1794-OB16 draws 8.0A.
What is the Allen-Bradley 1794-OB16?
The 1794-OB16 is an Allen-Bradley Flex I/O 1794 Flex I/O Digital DC Output Module.
1794-OB16
The Allen-Bradley 1794-OB16 is a Flex I/O Digital DC Output Module by Rockwell Automation, featuring 16 sourcing outputs, with a nominal 24V DC on-state voltage, 500mA max per channel, and a 0.5V DC max voltage drop. It allows for up to 8.0A output current rating and provides 50V continuous isolation, designed for efficient interfacing and control within industrial environments.
