| UPC | 10612598305961 |
| Brand | Allen-Bradley |
| Outputs | 16 Nonisolated |
| Manufacturer | Rockwell Automation |
| Product Type | Flex I/O Digital Output Module w/ Diagnostics |
| Flexbus Current | 60mA @ 5V DC |
| Isolation Voltage | 50V |
| Power Dissipation | 4.8W @ 31.2V DC max. |
| Output Signal Delay | 0.5 ms |
| Output Voltage nom. | 24V DC |
| Thermal Dissipation | 16.4 BTU/hr. @ 31.2V DC max. |
| On-state Current max. | 500mA per Channel |
| Output Current Rating | 8.0A |
| Off-state Leakage max. | 0.5mA |
| Part Number/Catalog No. | 1794-OB16D |
Does the Allen-Bradley 1794-OB16D come with a warranty?
Yes. The 1794-OB16D is backed by our 24-Month Replace Industrial Warranty, with no rush fees or hidden warranty charges. If a unit fails under normal use within the warranty period, we repair or replace it.
Is this 1794-OB16D a genuine Allen-Bradley part?
The 1794-OB16D is sourced and verified independently. Replace Industrial, LLC is not a Rockwell Automation Authorized Distributor, and all warranties are provided directly by Replace Industrial.
Is the Allen-Bradley 1794-OB16D new or used?
We offer the 1794-OB16D in multiple conditions, from unused surplus to professionally reconditioned units. Every option is sourced and verified independently and covered by our 2-year replacement warranty.
What are the key ratings of the 1794-OB16D?
The 1794-OB16D draws 8.0A.
What is the Allen-Bradley 1794-OB16D?
The 1794-OB16D is an Allen-Bradley Flex I/O 1794 Flex I/O Digital Output Module w/ Diagnostics.
1794-OB16D
The Allen-Bradley 1794-OB16D is a Flex I/O Digital Output Module by Rockwell Automation, featuring 16 non-isolated channels with a nominal 24V DC output. Designed for diagnostic purposes, its output signal delay is minimal at 0.5 ms, allowing for efficient system communication with a maximum on-state current of 500mA per channel.
All products are covered by our 2-Year (24-Month) Replace Industrial Warranty. If a unit is found defective under normal use within the warranty period, we repair or replace it at no additional cost, and a unit may be returned for a full refund within 30 days if returned in the same condition it was sent.
Replace Industrial is an independent distributor and does not convey the manufacturer's warranty; all warranties are provided by Replace Industrial alone. Read the full warranty policy
