Manufacturer	Allen-Bradley
Product Line	Kinetix 6000
Module Type	Axis Module
Voltage Class	200V Class
Nominal Input Voltage	325 VDC
AC Voltage Rating	230 VAC
Continuous Output Power	5.5 kW
Continuous Output Current	25 A
Continuous Current (rms)	17.3 A
Peak Current (rms)	34.6 A
Continuous Current (0-peak)	24.5 A
Peak Current (0-peak)	48.9 A
Velocity Loop Bandwidth	500 Hz
Current Loop Bandwidth	1300 Hz
PWM Frequency	4 kHz
Internal Shunt Continuous Power	50 W
Internal Shunt Peak Power	1400 W
Internal Shunt Resistor	115 Ω
Shunt Off Voltage	375 VDC
Shunt On Voltage	405 VDC
Efficiency	98%
Capacitance	1320 µF
Capacitive Energy Absorption	50 J
Short-Circuit Protection	200,000 A
Safe Torque Off	No
Weight	6.50 lbs (2.95 kg)
Minimum Cabinet Depth	198 mm (7.8 in.)

What is the continuous power output and current rating of the 2094-AM03?

The 2094-AM03 has a continuous output rating of 5.5 kW and 25 A. It features a continuous current (rms) of 17.3 Amperes and a continuous current (0-peak) of 24.5 Amperes.

Does the 2094-AM03 include internal shunt resistors?

Yes, the module is equipped with internal shunt resistors. The internal shunt has a continuous power rating of 50 W and a peak power rating of 1400 W. The internal shunt resistor value is 115 ohms, with a shunt off voltage of 375 VDC and a shunt on voltage of 405 VDC.

What are the supported bandwidths for the velocity and current loops?

The 2094-AM03 supports a bandwidth of 500 Hz for the velocity loop and 1300 Hz for the current loop.

What is the nominal input voltage and module class for this drive?

The 2094-AM03 is a 200 Volt Class module with a nominal input voltage of 325 VDC. It is designed for 230 VAC applications.

Does the 2094-AM03 feature Safe Torque-Off functionality?

No, the 2094-AM03 does not include the Safe Torque-Off feature. It is replaced by the 2094-AM03-S, which includes integrated Safe Torque-Off functionality compliant with Category 3 requirements according to EN ISO 13849-1.

What is the power dissipation of the 2094-AM03 at 100% rated power output?

According to the Kinetix 6000 User Manual, the power dissipation for the 2094-AM03-S (the successor to the 2094-AM03) at 100% of rated power output is 144 watts. Note that internal shunt power is not included in this calculation and must be added based on utilization.

Does the Allen-Bradley 2094-AM03 come with a warranty?

Yes. The 2094-AM03 is backed by our 24-Month Replace Industrial Warranty, with no rush fees or hidden warranty charges. If a unit fails under normal use within the warranty period, we repair or replace it.

Is this 2094-AM03 a genuine Allen-Bradley part?

The 2094-AM03 is sourced and verified independently. Replace Industrial, LLC is not a Rockwell Automation Authorized Distributor, and all warranties are provided directly by Replace Industrial.

Is the Allen-Bradley 2094-AM03 new or used?

We offer the 2094-AM03 in multiple conditions, from unused surplus to professionally reconditioned units. Every option is sourced and verified independently and covered by our 2-year replacement warranty.

What are the key ratings of the 2094-AM03?

The 2094-AM03 runs on 325 VDC, is rated at 5.5 kW, and draws 25 A.

What is the Allen-Bradley 2094-AM03?

The 2094-AM03 is an Allen-Bradley Kinetix 6000 Axis Module.

Allen-Bradley

2094-AM03

Rate this product

Drives Kinetix 6000

The Allen-Bradley 2094-AM03 is a Kinetix 6000 servo drive axis module with a "Safe Off" feature, offering a robust 34.6 Amp rms peak output current and designed for a 325V DC nominal input voltage. Tailored for K6000 applications, this module supports 230V AC and delivers up to 5.5kW of power.

PDF

We currently only collect tax from customers in the state of North Carolina. If you are exempt on your purchase, please email your Sales Tax & Use Exemption Form to sales@replacenc.com.
If you are checking out via a quote we send you, there is an option to upload your form at the time of purchase.

If you have already placed an order, please send us your form and we can refund the charged taxes.

Overview of Allen-Bradley 2094-AM03

The Allen-Bradley 2094-AM03 is a Kinetix 6000 axis module designed for 200/230V AC applications. This component serves as a direct connection to motors, providing precise axis control within the Kinetix 6000 drive system. It is a 200V-class module with a 24 A inverter rating, offering a continuous output of 5.5 kW and 25 A.

Key Features

This axis module features an integrated Safe Torque-Off functionality, which forces power transistors and control signals to a disabled state to ensure the drive coasts to a stop. The module is compliant with Category 3 requirements according to EN ISO 13849-1, maintaining safety functionality even when a single fault is detected. It includes internal shunt resistors with a continuous power rating of 50 W and a peak power rating of 1400 W.

Performance and Capacity

The 2094-AM03 operates with a nominal input voltage of 325V DC and supports a 230V AC voltage rating. It delivers a continuous RMS current of 17.3 A, which can peak at 34.6 A, and a continuous 0-peak current of 24.5 A. The module features a velocity loop bandwidth of 500 Hz and a current loop bandwidth of 1300 Hz, with a Pulse Width Modulation (PWM) frequency of 4 kHz. Overall operational efficiency is 98%, with a drive capacitance of 1320 µF and capacitive energy absorption of 50 J.

Installation and Compatibility

Designed for single-slot usage, the 2094-AM03 requires a minimum cabinet depth of 198 mm (7.8 in.) when using 2090-K6CK-xxxx low-profile connector kits. Up to seven 2094-AM01-S modules may be used for each eight-axis power rail. The module is part of the Kinetix 6000 family and is compatible with the 2094-PRx power rail, which extends approximately 25.4 mm (1.0 in.) left of the IAM module and right of the last module mounted on the rail.

Applications and Industries

The 2094-AM03 is tailored for Kinetix 6000 applications requiring robust servo control in industrial automation environments. Its Safe Torque-Off feature and high-efficiency performance make it suitable for machinery where safety and precise motion control are critical, such as packaging, material handling, and manufacturing systems.
