Is the Allen-Bradley 5069-L306ER new or used?

We offer the 5069-L306ER in multiple conditions, from unused surplus to professionally reconditioned units. Every option is sourced and verified independently and covered by our 2-year replacement warranty.

What is the Allen-Bradley 5069-L306ER?

The 5069-L306ER is an Allen-Bradley CompactLogix 5069 Controller.

How fast does the 5069-L306ER ship?

In-stock orders for the 5069-L306ER ship the same day when placed before our daily cutoff. Expedited and same-day air options are available if you are facing downtime, with no rush fees. Our team is based in Raleigh, North Carolina.

Brand	Allen-Bradley
Weight	0.39 lbs (175 g)
Dimensions	5.4 x 0.9 x 4.2 in (138 x 22 x 105 mm)
Module Type	Controller
Motion Axes	0 Motion Axes
Manufacturer	Rockwell Automation
I/O Expansion	8 I/O
Ethernet/IP Nodes	16 Ethernet/IP Nodes
Application Memory	0.6 Megabytes
Communication Ports	1 Type B 2.0 Full-Speed USB and 2 Ethernet/IP Ports (10 Mbps, 100 Mbps, 1 Gbps)
Programming Languages	Sequential Function Chart, Function Block Diagram, Structured Text, and Ladder Diagram
Part Number/Catalog No.	5069-L306ER
Pulse Latching Supported	Yes
Pattern Matching Supported	Yes
Supported Ethernet/IP Network Topologies	Device Level Ring, Star, and Linear

Allen-Bradley

5069-L306ER

Rate this product

Ready to ShipPLCs CompactLogix 5069

The Allen-Bradley 5069-L306ER by Rockwell Automation is a compact controller with 0.6MB memory, supporting up to 16 Ethernet/IP nodes with device level ring, star, and linear topologies. It accommodates 8 I/O expansions, offers USB and dual Ethernet/IP communication ports, and is capable of multiple programming languages. Ideal for streamlined automation tasks.

PDF

We currently only collect tax from customers in the state of North Carolina. If you are exempt on your purchase, please email your Sales Tax & Use Exemption Form to sales@replacenc.com.
If you are checking out via a quote we send you, there is an option to upload your form at the time of purchase.

If you have already placed an order, please send us your form and we can refund the charged taxes.

Overview of Allen-Bradley 5069-L306ER

The Allen-Bradley 5069-L306ER is a compact programmable logic controller (PLC) that belongs to the CompactLogix 5000 series of controllers. It's designed to cater to mid-range application solutions and delivers high-performance capabilities within a compact and modular design. This PLC is widely used for control systems in various industrial environments due to its reliability, versatility, and advanced features.

Specifications and Performance

The 5069-L306ER features a dual-core processor that provides exceptional speed and performance for complex automation tasks. It comes with an integrated Ethernet port for communication, enabling easy connectivity and data sharing across networks. The controller supports up to 32 tasks and 100 programs per task, allowing it to efficiently handle multiple processes simultaneously. With 3 MB of application memory, it offers ample space for user programs and data.

Input/Output Capacity

This compact controller is equipped with an integrated I/O capacity which comprises 16 DC inputs and 16 DC outputs. This I/O configuration is suitable for managing a wide range of sensors and actuators directly from the controller. Additionally, the 5069-L306ER allows for further expansion with additional I/O modules to suit various application needs, ensuring scalability and flexibility for growing systems.

Software and Integration

The 5069-L306ER is engineered to work seamlessly with Rockwell Automation's integrated engineering environment, Studio 5000. This software streamlines the development process by offering an intuitive interface for programming, configuration, and diagnostics. Integration with other devices and platforms within the Rockwell Automation ecosystem is simplified thanks to the common development environment.

Safety and Security Features

Allan-Bradley places a high emphasis on safety and security in its products. The 5069-L306ER is no exception, as it supports embedded safety instructions and has provisions for safety-related communication. The PLC also incorporates security measures such as user authentication and role-based access control to safeguard against unauthorized configuration changes and protect industrial processes from potential risks.
