Is the Allen-Bradley 5069-OB8 new or used?

We offer the 5069-OB8 in multiple conditions, from unused surplus to professionally reconditioned units. Every option is sourced and verified independently and covered by our 2-year replacement warranty.

What is the Allen-Bradley 5069-OB8?

The 5069-OB8 is an Allen-Bradley CompactLogix 5069 DC Digital Output.

Brand	Allen-Bradley
Weight	0.39 lbs (175 g)
Dimensions	5.4 x 0.87 x 4.2 in (138 x 22 x 105 mm)
Module Type	DC Digital Output
Manufacturer	Rockwell Automation
Enclosure Type	None (Open Style)
Number of Inputs	N/A
Voltage Category	24 Volts DC
Number of Outputs	8 (2 Groups of 4) Channels
Power Dissipation	3.2 Watts
CIP Sync Supported	Yes
Input Voltage Range	N/A
Output Voltage Range	10-32 Volts DC
Part Number/Catalog No.	5069-OB8
Pattern Matching Supported	Yes

Allen-Bradley

5069-OB8

Rate this product

Ready to ShipPLCs CompactLogix 5069

The Allen-Bradley 5069-OB8 is a DC digital output module by Rockwell Automation, featuring 8 channels across two groups. Designed for 24V DC systems with an output range of 10-32V DC, it supports CIP Sync and pattern matching, all within its compact 5.4 x 0.87 x 4.2 inch frame.

PDF

We currently only collect tax from customers in the state of North Carolina. If you are exempt on your purchase, please email your Sales Tax & Use Exemption Form to sales@replacenc.com.
If you are checking out via a quote we send you, there is an option to upload your form at the time of purchase.

If you have already placed an order, please send us your form and we can refund the charged taxes.

Overview of Allen-Bradly 5069-OB8

The Allen-Bradley 5069-OB8 is a state-of-the-art digital output module designed for use with the CompactLogix 5000 and Compact GuardLogix 5000 systems. As part of the 5069 Compact I/O series, it offers high-performance control in a compact format, allowing users to optimize their automation system's space while maintaining functionality and reliability.

Features and Specifications

This module supports eight individually isolated 24V DC sink outputs, handling a wide range of high-speed applications with exceptional precision. The 5069-OB8 module also features built-in diagnostics, electronic circuit protection, and provides a current output of 2A per point, with a total module output current of 8A. Its robust design ensures that it can operate effectively in challenging industrial environments with a wide temperature range.

Installation and Compatibility

Installation of the Allen-Bradley 5069-OB8 is user-friendly, thanks to its removable terminal blocks which simplify wiring tasks. The module can be easily snapped onto the Compact 5000 I/O system's mounting base, which supports DIN rail or panel mounting. It is also designed to integrate seamlessly with Rockwell Automation's Studio 5000 Logix Designer®, allowing for efficient configuration and commissioning within an integrated automation environment.

Performance and Reliability

The 5069-OB8 module has been engineered for high-performance, providing rapid response times suitable for demanding applications. Moreover, its built-in diagnostics contribute to lower system downtime by aiding in the quick identification of faults and minimizing maintenance efforts. The status of each point is clearly indicated by LEDs, facilitating real-time operational monitoring and troubleshooting.

Communication and Network Integration

As part of the CompactLogix platform, the Allen-Bradley 5069-OB8 benefits from seamless integration with various communication networks including EtherNet/IP. This allows for efficient data exchange, remote access, and synchronization with other devices within the system network, thus enhancing the capabilities of the control system it is part of.
