Is the Allen-Bradley 5069-OF8 new or used?

We offer the 5069-OF8 in multiple conditions, from unused surplus to professionally reconditioned units. Every option is sourced and verified independently and covered by our 2-year replacement warranty.

What is the Allen-Bradley 5069-OF8?

The 5069-OF8 is an Allen-Bradley CompactLogix 5069 Analog Output.

UPC	885630530116
Brand	Allen-Bradley
Weight	0.39 lbs (175 g)
Dimensions	5.4 x 0.9 x 4.2 in (138 x 22 x 105 mm)
Module Type	Analog Output
Manufacturer	Rockwell Automation
Enclosure Type	None (Open Style)
Number of Inputs	N/A
Voltage Category	N/A
Number of Outputs	8 Voltage or Current Outputs
Power Dissipation	5.3 Watts
CIP Sync Supported	Yes
Input Voltage Range	N/A
Output Voltage Range	+/- 10 Volts, 0-10 Volts, 0-5 Volts
Part Number/Catalog No.	5069-OF8
Pattern Matching Supported	Yes

Allen-Bradley

5069-OF8

Rate this product

PLCs CompactLogix 5069

The Allen-Bradley 5069-OF8 is an analog output module with 8 voltage or current outputs, allowing a range of +/- 10 volts to 0-5 volts. This compact unit, with dimensions of 5.4 x 0.9 x 4.2 inches, supports CIP Sync and pattern matching, enhancing versatility for various automation applications.

PDF

We currently only collect tax from customers in the state of North Carolina. If you are exempt on your purchase, please email your Sales Tax & Use Exemption Form to sales@replacenc.com.
If you are checking out via a quote we send you, there is an option to upload your form at the time of purchase.

If you have already placed an order, please send us your form and we can refund the charged taxes.

Overview of Allen-Bradley 5069-OF8

The Allen-Bradley 5069-OF8 is a compact I/O module specifically designed for use with the Rockwell Automation Logix 5000 control systems. It is part of the CompactLogix 5000 series and features eight channels of analog voltage or current output. The module allows for precise control of various output signals, making it well-suited for industrial processes that require such functionality.

Key Features

The 5069-OF8 module boasts several key features, including its high-resolution outputs, configurable output range selection, and on-board scaling. It supports different output ranges such as 0-20 mA, 4-20 mA, 0-10 V, and +/-10 V, allowing for versatility in control applications. Additionally, the module features individually isolated channels for enhanced accuracy and safety, eliminating the risk of channel-to-channel interference.

Integration and Compatibility

Integration of the 5069-OF8 module into an existing control system is made seamless with Studio 5000 Logix Designer software that provides a user-friendly environment for configuring and monitoring the module. The software also allows for easy access to diagnostics and troubleshooting data. Compatibility with the CompactLogix 5380 controllers and Compact 5000 I/O systems ensures that the module can be used efficiently across different hardware configurations within the Rockwell Automation architecture.

Performance and Accuracy

The Allen-Bradley 5069-OF8 is engineered to deliver high performance in demanding industrial environments. It offers real-time control with superior accuracy and low output ripple, catering to applications that necessitate precise control over their processes. With diagnostics that can detect open-circuit conditions, under and over-range signals, and module health status, it maintains reliable performance and minimizes downtime due to unforeseen issues.

Installation and Maintenance

Designed for easy installation, the 5069-OF8 module utilizes a removable terminal block that simplifies the wiring process. Its compact design saves valuable panel space without sacrificing functionality. Maintenance is also straightforward, as the clear LED indicators provide immediate status updates and facilitate quick identification of any issues, ensuring minimal impact on production flow.
