Manufacturer	Schneider Electric
Product type	Power supply module
Power supply function	Redundant
Product line	Modicon Quantum
Input voltage	115/230 V AC
Input frequency	50/60 Hz
Input current	1100 mA at 115 V and 600 mA at 230 V
Inrush current	38 A at 115 V and 19 A at 230 V
Rated power	130 VA
Fuse rating	2 A, slow-blow
Output voltage	5.1 V DC
Operating altitude	5000 m
Relative humidity	95% without condensation
Ambient operating temperature	0 to 60 °C
Ambient storage temperature	-40 to 85 °C
Weight	2.00 lbs (0.91 kg)

What is the 140CPS12400?

The 140CPS12400 is a Schneider Electric redundant power supply module for the Modicon Quantum automation platform.

What input voltages does the 140CPS12400 support?

It supports 115 V AC and 230 V AC input.

What are the input current ratings?

The input current is 1100 mA at 115 V AC and 600 mA at 230 V AC.

What are the inrush current ratings?

The inrush current is 38 A at 115 V AC and 19 A at 230 V AC.

What output voltage and rated power does the module provide?

The module provides a 5.1 V DC output and has a rated power of 130 VA.

What fuse rating is associated with the 140CPS12400?

The associated fuse rating is 2 A, slow-blow.

How is the module's power status indicated?

A single green PWR OK LED provides local power-status indication.

What operating conditions are supported?

The module can operate from 0 to 60 °C, at altitudes up to 5000 m, and at relative humidity up to 95% without condensation.

What storage temperature range is specified?

The specified storage temperature range is -40 to 85 °C.

Does the Schneider Electric 140CPS12400 come with a warranty?

Yes. The 140CPS12400 is backed by our 24-Month Replace Industrial Warranty, with no rush fees or hidden warranty charges. If a unit fails under normal use within the warranty period, we repair or replace it.

Is this 140CPS12400 a genuine Schneider Electric part?

The 140CPS12400 is sourced and verified independently. Replace Industrial is not an authorized distributor, affiliate, or representative of Schneider Electric, and all warranties are provided directly by Replace Industrial.

Is the Schneider Electric 140CPS12400 new or used?

We offer the 140CPS12400 in multiple conditions, from unused surplus to professionally reconditioned units. Every option is sourced and verified independently and covered by our 2-year replacement warranty.

What are the key ratings of the 140CPS12400?

The 140CPS12400 runs on 115/230 V AC, draws 1100 mA at 115 V and 600 mA at 230 V, and is rated at 130 VA.

What is the Schneider Electric 140CPS12400?

The 140CPS12400 is a Schneider Electric Modicon Quantum Power supply module.

Schneider Electric

140CPS12400

Rate this product

PLCs Modicon Quantum

The Schneider Electric 140CPS12400 is a redundant Modicon Quantum power supply module for industrial automation systems. It accepts 115 or 230 V AC input, provides a 5.1 V DC output, and is rated at 130 VA. Input current is 1100 mA at 115 V and 600 mA at 230 V, with inrush current of 38 A and 19 A respectively. A 2 A slow-blow fuse is associated with the module, and a green PWR OK LED provides local status indication. It supports operation from 0 to 60 °C, up to 5000 m altitude, and 95% relative humidity without condensation.

PDF

We currently only collect tax from customers in the state of North Carolina. If you are exempt on your purchase, please email your Sales Tax & Use Exemption Form to sales@replacenc.com.
If you are checking out via a quote we send you, there is an option to upload your form at the time of purchase.

If you have already placed an order, please send us your form and we can refund the charged taxes.

Overview of Schneider Electric 140CPS12400

The Schneider Electric 140CPS12400 is a redundant power supply module in the Modicon Quantum product line for industrial automation systems.

It accepts 115 or 230 V AC input and provides a 5.1 V DC output, with a green PWR OK LED for local status indication.

Key Features

The module is rated at 130 VA and uses an associated 2 A slow-blow fuse. Its redundant power-supply design supports continuity requirements within compatible Modicon Quantum installations.

One green PWR OK indicator provides straightforward visual monitoring of module status.

Performance and Capacity

At 115 V AC, the input current is 1100 mA and inrush current is 38 A. At 230 V AC, input current is 600 mA and inrush current is 19 A.

The output voltage is 5.1 V DC. The module supports ambient operating temperatures from 0 to 60 °C, altitudes up to 5000 m, and relative humidity up to 95% without condensation.

Installation and Compatibility

The 140CPS12400 is designed for use with Schneider Electric Modicon Quantum systems and accepts either 115 V AC or 230 V AC.

Installation planning should account for the specified input current, startup inrush current, and associated 2 A slow-blow fuse.

Applications and Industries

This power supply module is intended for industrial automation applications that require a redundant power supply within the Modicon Quantum product line.

Its broad operating-temperature range, high altitude rating, and condensation-free humidity tolerance support use across a range of industrial environments.
