| UPC | 10612598329103 |
| Brand | Allen-Bradley |
| Series | ControlLogix |
| UNSPSC | 32151705 |
| Location | Chassis (any slot) |
| Slot Width | 1 |
| Current Draw | 1 Amp |
| Manufacturer | Industrial Automation |
| Product Type | Ethernet Communication Module |
| Current Rating | 1.2 Amps |
| Integrated Ports | One (1) RJ45; One (1) USB 1.1 |
| Power Dissipation | 6.2 W |
| Insulation Voltage | 30 Volts Continuous |
| Thermal Dissipation | 21.28 BTU per hour |
| Operating Temperature | 32 to 140 degrees Fahrenheit (0 to 60 degrees Celsius) |
| Configuration Software | RSLogix 5000; Studio 5000 Logix Designer |
| Part Number/Catalog No. | 1756-EN2T |
| Ethernet-IP Communication Rate | 10/100 Mbps |
What is the communication rate of the 1756-EN2T?
The 1756-EN2T supports Ethernet-IP communication at rates of 10/100 Mbps.
Where can the 1756-EN2T be installed within a ControlLogix system?
This module is designed to fit into any available slot in the ControlLogix chassis.
What is the power dissipation rating for the 1756-EN2T?
The module has a maximum power dissipation rating of 5.1 watts.
What is the current draw of the 1756-EN2T?
The backplane current rating is 1 Amp at 5.1 Volts DC and 3 Milliamps at 24 Volts DC.
What is the operating temperature range for the 1756-EN2T?
The module operates in temperatures ranging from 0 to 60 degrees Celsius (32 to 140 degrees Fahrenheit).
Does the 1756-EN2T have isolation between the USB port and the backplane?
No, there is no isolation between the USB interface and the backplane, though the module has a continuous insulation voltage rating of 30 Volts.
Does the Allen-Bradley 1756-EN2T come with a warranty?
Yes. The 1756-EN2T is backed by our 24-Month Replace Industrial Warranty, with no rush fees or hidden warranty charges. If a unit fails under normal use within the warranty period, we repair or replace it.
Is this 1756-EN2T a genuine Allen-Bradley part?
The 1756-EN2T is sourced and verified independently. Replace Industrial, LLC is not a Rockwell Automation Authorized Distributor, and all warranties are provided directly by Replace Industrial.
Is the Allen-Bradley 1756-EN2T new or used?
We offer the 1756-EN2T in multiple conditions, from unused surplus to professionally reconditioned units. Every option is sourced and verified independently and covered by our 2-year replacement warranty.
What are the key ratings of the 1756-EN2T?
The 1756-EN2T draws 1 Amp and operates across 32 to 140 degrees Fahrenheit (0 to 60 degrees Celsius).
What is the Allen-Bradley 1756-EN2T?
The 1756-EN2T is an Allen-Bradley ControlLogix 1756 Ethernet Communication Module.
1756-EN2T
The Allen-Bradley 1756-EN2T is a ControlLogix Ethernet Communication Module from Industrial Automation. Designed for robust networking, it offers 10/100 Mbps Ethernet-IP rate via RJ45 and USB 1.1 ports. Rated at 30V continuous insulation, it fits any chassis slot, draws 1 amp, and operates from 0-60°C, facilitating seamless integration and connectivity.
All products are covered by our 2-Year (24-Month) Replace Industrial Warranty. If a unit is found defective under normal use within the warranty period, we repair or replace it at no additional cost, and a unit may be returned for a full refund within 30 days if returned in the same condition it was sent.
Replace Industrial is an independent distributor and does not convey the manufacturer's warranty; all warranties are provided by Replace Industrial alone. Read the full warranty policy
We repair a wide range of industrial automation equipment, including PLCs, HMIs, drives, servo motors, switches, and circuit breakers, with rush service for critical downtime. Request a quote, ship your unit, and we diagnose, repair, and return it. Request a repair quote
