Is the Allen-Bradley 1756-PA75R new or used?

We offer the 1756-PA75R in multiple conditions, from unused surplus to professionally reconditioned units. Every option is sourced and verified independently and covered by our 2-year replacement warranty.

What are the key ratings of the 1756-PA75R?

The 1756-PA75R runs on 120-220 Volts AC and operates across 32-140 Fahrenheit (0-60 Celsius).

What is the Allen-Bradley 1756-PA75R?

The 1756-PA75R is an Allen-Bradley ControlLogix 1756 Redundant AC Power Supply Module.

UPC	10612598274229
Brand	Allen-Bradley
Series	ControlLogix
UNSPSC	32151706
Weight	3.2 pounds (1.45 kilograms)
Chassis	Series B
Location	Panel Mounted
Enclosure	None
Dimensions	6.9 x 5.7 x 5.4 inches
Input Power	115 Watts
Module Type	Redundant AC Power Supply Module
Manufacturer	Rockwell Automation
Power Output	75 Watts at 60 Celsius
Input Voltage	120-220 Volts AC
Voltage Range	85-265 Volts AC
Input Frequency	47-63 Hertz
Operating Temperature	32-140 Fahrenheit (0-60 Celsius)
Part Number/Catalog No.	1756-PA75R

Allen-Bradley

1756-PA75R

Rate this product

Ready to ShipPLCs ControlLogix 1756

The Allen-Bradley 1756-PA75R is a ControlLogix Redundant AC Power Supply Module from Rockwell Automation designed for reliability in automation systems. With an input voltage of 120-220V AC and output power of 75 Watts at 60 Celsius, it ensures consistent performance. This panel-mounted unit, weighing 3.2 pounds, fits within a Series B chassis and operates between 32-140 Fahrenheit.

PDF

We currently only collect tax from customers in the state of North Carolina. If you are exempt on your purchase, please email your Sales Tax & Use Exemption Form to sales@replacenc.com.
If you are checking out via a quote we send you, there is an option to upload your form at the time of purchase.

If you have already placed an order, please send us your form and we can refund the charged taxes.

Allen-Bradley 1756-PA75R Overview

The Allen-Bradley 1756-PA75R is a ControlLogix Redundant Power Supply designed to provide reliable power to a ControlLogix system. It is part of Rockwell Automation's large portfolio of automation equipment and is specifically engineered to be used in setups that require high availability and redundancy, ensuring that the system remains operational even in the event of a power supply failure.

Power Supply Features

This model is a rack-mounted power supply that ensures a continuous power delivery of 75 Watts at 24V DC. The 1756-PA75R comes with built-in features such as overcurrent and overvoltage protection, leading to improved safety and durability of the power supply and the components it powers. It can operate at a wide range of input voltages, allowing for versatility in various applications and geographical regions.

Redundancy Capabilities

The unique feature of the Allen-Bradley 1756-PA75R is its redundancy capability, which means it is typically used in conjunction with another power supply within the same system to provide redundant power. This means if one power supply were to fail, the other could immediately take over without causing any downtime or loss of function to the connected devices. This is particularly important in critical industries where uptime is of utmost importance.

Compatibility and Integration

As part of the ControlLogix platform, the 1756-PA75R is designed to integrate smoothly with other ControlLogix components such as controllers, I/O modules, and communication modules. This enables a seamless and efficient setup within an automated control system. The integration allows for ease of use and maintenance, as well as scalability for system expansions or upgrades.

Installation and Maintenance

The Allen-Bradley 1756-PA75R has been designed with the industrial environment in mind. It is robust and can be easily installed into a standard ControlLogix chassis. Its module design allows for quick replacement, minimizing downtime during maintenance or in the event of a failure. Additionally, the power supply features diagnostic indicators that help in monitoring its status and performing troubleshooting if necessary.
