BrandAllen-Bradley
SeriesControlLogix
Outputs32-Point
Voltage12-24 Volts DC Source
EnclosureNone
Module TypeDC Output Module
ManufacturerRockwell Automation
Isolation Voltage50 Volts Continuous
Operating Voltage Range10-31.2 Volts DC
Part Number/Catalog No.1756-OB32K
Power Dissipation (Max)4.8 Watts at 60 degrees Celsius
Backplane Current at 5 Volts300 milliamps
Removeable Terminal Block(s)1756-TBCH, 1756-TBS6H
Maximum Output Current Rating-Point0.5 Amps at 50 Celsius, 0.35 Amps at 60 Celsius
Maximum Output Current Rating-Module16 Amps at 50 Celsius, 10 Amps at 60 Celsius
Allen-Bradley

1756-OB32K

4.8 (4)
PLCsControlLogix 1756

The Allen-Bradley 1756-OB32K is a ControlLogix DC output module by Rockwell Automation, featuring 32 outputs with a 12-24V DC source. It supports an operating voltage range of 10-31.2V DC and delivers a per-point output current up to 0.5A. The module can handle 16A per module, has a 4.8W power dissipation, and offers removable terminal blocks for flexibility.
