| Brand | Allen-Bradley |
| Series | ControlLogix |
| Outputs | 16-Point |
| Voltage | 5 Volts DC with TTL Source |
| Enclosure | None |
| Module Type | Digital DC Ouptut Module |
| Manufacturer | Rockwell Automation |
| Isolation Voltage | 50 Volts Continuous |
| Operating Voltage Range | 4.5-5.5 Volts DC |
| Part Number/Catalog No. | 1756-OG16 |
| Power Dissipation (Max) | 1.5 Watts at 60 Celsius |
| Backplane Current at 5 Volts | 210 milliamps |
| Removeable Terminal Block(s) | 1756-TBNH, 1756-TBSH |
| Maximum Output Current Rating-Point | 24 milliamps at 60 Celsius |
| Maximum Output Current Rating-Module | 384 milliamps at 60 Celsius |
Does the Allen-Bradley 1756-OG16 come with a warranty?
Yes. The 1756-OG16 is backed by our 24-Month Replace Industrial Warranty, with no rush fees or hidden warranty charges. If a unit fails under normal use within the warranty period, we repair or replace it.
Is this 1756-OG16 a genuine Allen-Bradley part?
The 1756-OG16 is sourced and verified independently. Replace Industrial, LLC is not a Rockwell Automation Authorized Distributor, and all warranties are provided directly by Replace Industrial.
Is the Allen-Bradley 1756-OG16 new or used?
We offer the 1756-OG16 in multiple conditions, from unused surplus to professionally reconditioned units. Every option is sourced and verified independently and covered by our 2-year replacement warranty.
What are the key ratings of the 1756-OG16?
The 1756-OG16 runs on 4.5-5.5 Volts DC and draws 24 milliamps at 60 Celsius.
What is the Allen-Bradley 1756-OG16?
The 1756-OG16 is an Allen-Bradley ControlLogix 1756 Digital DC Ouptut Module.
1756-OG16
The Allen-Bradley 1756-OG16 is a ControlLogix Digital DC Output Module from Rockwell Automation with 16 TTL-compatible 5V DC points. It allows a max of 24mA per point and 384mA for the module, boasting a 1.5W power dissipation and 210mA backplane current. It accepts 1756-TBNH/TBSH terminal blocks, ensuring reliable performance in various industrial settings.
