Is the Allen-Bradley 1762-IF4 new or used?

We offer the 1762-IF4 in multiple conditions, from unused surplus to professionally reconditioned units. Every option is sourced and verified independently and covered by our 2-year replacement warranty.

What are the key ratings of the 1762-IF4?

The 1762-IF4 runs on -10.5 to 10 Volts DC.

What is the Allen-Bradley 1762-IF4?

The 1762-IF4 is an Allen-Bradley MicroLogix 1200 Analog Input Module.

UPC	10611320152125
Brand	Allen-Bradley
Inputs	4 Differential (Bipolar)
Series	MicroLogix 1200
Converter	Delta-Sigma
Dimensions	90 x 87 x 40.4 millimeters
Resolution	15 bit
Manufacturer	Rockwell Automation
Product Type	Analog Input Module
Mounting Type	DIN Rail or Panel
No. of Inputs	Four (4) Differential (Bipolar)
Repeatability	Â±0.12%
Product Family	MicroLogix
Shipping Weight	8.28 ounces
Status Indicator	Single source LED
Recommended Cable	Belden 8761 (shielded)
Enclosure Type Rating	IP20
Part Number/Catalog No.	1762-IF4
Current signal full range	-21 â€¦ +21 m
Current signal normal ranges	4 â€¦ 20 mA
Voltage signal normal ranges	'-10.5 â€¦ +10.5V dc
Analog Normal Operating Voltage	-10.5 to 10 Volts DC

Allen-Bradley

1762-IF4

Rate this product

Ready to ShipPLCs MicroLogix 1200

The Allen-Bradley 1762-IF4 is a compact MicroLogix 1200 analog input module with 4 differential bipolar inputs, offering a voltage range of -10.5 to +10.5V DC and current range of 4 to 20 mA. It features a 15-bit Delta-Sigma converter, ±0.12% repeatability, DIN rail or panel mounting options, and IP20 enclosure type rating, making it a robust choice for adaptable control systems.

PDF

We currently only collect tax from customers in the state of North Carolina. If you are exempt on your purchase, please email your Sales Tax & Use Exemption Form to sales@replacenc.com.
If you are checking out via a quote we send you, there is an option to upload your form at the time of purchase.

If you have already placed an order, please send us your form and we can refund the charged taxes.

Allen-Bradley 1762-IF4 Overview

The Allen-Bradley 1762-IF4 is an analog input module that is part of the MicroLogix 1200 system. Designed for industrial applications, this module provides a compact solution for integrating analog input signals into a micro PLC setup. The 1762-IF4 module supports four differential or single-ended inputs, allowing for versatile use in various control and monitoring tasks.

Key Features

The 1762-IF4 module boasts several key features that make it a reliable addition to the MicroLogix family. It offers a range of input types, including 0-10V, 0-20mA, or 4-20mA, which are common standards in industrial sensor signals. With high-resolution analog input conversion, the accuracy of signal reading is ensured. Moreover, the module has user-configurable filtering and data format options which can be tailored to specific application needs.

Installation and Configuration

Installation of the Allen-Bradley 1762-IF4 is straightforward thanks to its modular design, which allows for seamless integration with the MicroLogix 1200 system. The module connects to the PLC through a bus connector, ensuring efficient communication with the main processor. Configuration of the module is done using the RSLogix 500 software, where users can set up the input ranges, engineering units, and other parameters as per requirements.

Compatibility and Integration

The 1762-IF4 analog input module is designed to be compatible with other components in the MicroLogix range, including the MicroLogix 1100, 1200, and 1400 series PLCs, making it an adaptable solution for expanding existing systems. Furthermore, its integration capabilities ensure that it can work alongside HMI screens, motor controllers, and other automation equipment, contributing to a cohesive and efficient industrial environment.

Reliability and Performance

Allen-Bradley products are known for their reliability and the 1762-IF4 is no exception. It is built to withstand the harsh conditions of industrial environments, including exposure to temperature extremes, electrical noise, and vibration. With strong performance in accurate data acquisition and processing, the module helps maintain the precision and reliability of automated processes and machinery control.
