| UPC | 10662468153246 |
| Brand | Allen-Bradley |
| Series | MicroLogix |
| Outputs | (4) Analog |
| Dimensions | 90 x 87 x 40 mm (HxDxW) |
| Resolution | 12 bits (unipolar) |
| Input Power | 24 Volts DC |
| Manufacturer | Rockwell Automation |
| Output Range | 0-10 Volts DC |
| Product Type | Analog Output Module |
| Repeatability | ±0.12% |
| Converter Type | R-2R Ladder Voltage Switching |
| No. of Outputs | Four (4) Single-ended |
| Heat Dissipation | 2.8 Watts |
| Recommended cable | Belden 8761 (shielded) |
| Part Number/Catalog No. | 1762-OF4 |
| Full scale analog ranges | 0…10.5V DC; 0…21 mA |
| Typical overall accuracy | ±1.17% full scale at -20 °C…65 °C (-4 °F…149 °F) ±0.5% full scale at 25 °C (77 °F) |
| Analog normal operating range | 0-10 Volts DC; 4-20 mA |
Does the Allen-Bradley 1762-OF4 come with a warranty?
Yes. The 1762-OF4 is backed by our 24-Month Replace Industrial Warranty, with no rush fees or hidden warranty charges. If a unit fails under normal use within the warranty period, we repair or replace it.
Is this 1762-OF4 a genuine Allen-Bradley part?
The 1762-OF4 is sourced and verified independently. Replace Industrial, LLC is not a Rockwell Automation Authorized Distributor, and all warranties are provided directly by Replace Industrial.
Is the Allen-Bradley 1762-OF4 new or used?
We offer the 1762-OF4 in multiple conditions, from unused surplus to professionally reconditioned units. Every option is sourced and verified independently and covered by our 2-year replacement warranty.
What is the Allen-Bradley 1762-OF4?
The 1762-OF4 is an Allen-Bradley MicroLogix 1200 Analog Output Module.
How fast does the 1762-OF4 ship?
In-stock orders for the 1762-OF4 ship the same day when placed before our daily cutoff. Expedited and same-day air options are available if you are facing downtime, with no rush fees. Our team is based in Raleigh, North Carolina.
1762-OF4
The Allen-Bradley 1762-OF4, part of Rockwell Automation's MicroLogix series, is an Analog Output Module offering four single-ended outputs with 12-bit resolution across 0-10V DC or 4-20mA. It operates on 24V DC power, ensuring precision with typical accuracy and repeatability. Dimensions are 90 x 87 x 40 mm, and it uses Belden 8761 cabling.
