| UPC | 10612598207234 |
| Brand | Allen-Bradley |
| Inputs | (20) 24 Volts DC and (4) Fast 24 Volts DC |
| Outputs | (16) Relay |
| Dimensions | Height: 90 mm 104 mm (with DIN latch open); Width: 160 mm; Depth: 87 mm |
| Input Power | 120 to 240 Volts AC |
| Load Current | 10A, minimum |
| Manufacturer | Rockwell Automation |
| No. of Inputs | Twenty-Four (24) |
| No. of Outputs | Sixteen(16) |
| Shipping Weight | 2.4 pounds |
| Mechanical Cycles | 20,000,000 |
| Input Circuit Type | 24 Volts DC Sink/Source |
| Power Supply Usage | 82 VA |
| Operating Frequency | 47 to 63 Hertz |
| Output Circuit Type | Relay |
| Programming Software | RSLogix 500 |
| Relay Contact Rating | 24-125VDC; 120-240VAC |
| Internal Power Supply | Yes |
| Operating Temperature | 0 to 50 degrees Celsius |
| Ambient Operating Temp | 0 to 55 degrees Celsius |
| Part Number/Catalog No. | 1762-L40BWA |
| Power supply inrush current | 120V ac: 25A for 8 ms; 240V ac: 40A for 4 ms |
Does the Allen-Bradley 1762-L40BWA come with a warranty?
Yes. The 1762-L40BWA is backed by our 24-Month Replace Industrial Warranty, with no rush fees or hidden warranty charges. If a unit fails under normal use within the warranty period, we repair or replace it.
Is this 1762-L40BWA a genuine Allen-Bradley part?
The 1762-L40BWA is sourced and verified independently. Replace Industrial, LLC is not a Rockwell Automation Authorized Distributor, and all warranties are provided directly by Replace Industrial.
Is the Allen-Bradley 1762-L40BWA new or used?
We offer the 1762-L40BWA in multiple conditions, from unused surplus to professionally reconditioned units. Every option is sourced and verified independently and covered by our 2-year replacement warranty.
What are the key ratings of the 1762-L40BWA?
The 1762-L40BWA runs at 47 to 63 Hertz and operates across 0 to 50 degrees Celsius.
What is the Allen-Bradley 1762-L40BWA?
The 1762-L40BWA is part of the Allen-Bradley MicroLogix 1200 line.
1762-L40BWA
The Allen Bradley MicroLogix 1200 1762-L40BWA, by Rockwell Automation, is a compact PLC featuring 24 DC inputs, 16 relay outputs, and robust relay contact ratings suitable for a variety of industrial applications. It operates on 120-240V AC, supports sink/source input circuit types, and is programmable with RSLogix 500 software.
