Is the Allen-Bradley 1762-OW16 new or used?

We offer the 1762-OW16 in multiple conditions, from unused surplus to professionally reconditioned units. Every option is sourced and verified independently and covered by our 2-year replacement warranty.

What are the key ratings of the 1762-OW16?

The 1762-OW16 runs on 5-265V AC; 5-125V DC.

What is the Allen-Bradley 1762-OW16?

The 1762-OW16 is an Allen-Bradley MicroLogix 1200 Relay Output Module.

UPC	10611320152149
Brand	Allen-Bradley
Series	MicroLogix
Outputs	(16) AC/DC Relay
Module Type	Relay Output Module
Manufacturer	Rockwell Automation
Signal Delay	10 ms
Mounting Type	DIN Rail; Panel Mounting
No. of Groups	Two (2)
Isolated Groups	2
Shipping Weight	0.63 pounds
Heat Dissipation	6.1 Watts
Voltage Category	AC/DC Normally Open Relay
Channels Per group	Eight (8)
Compatible Controllers	MicroLogix 1100 / 1200 / 1400
Configuration Software	RSLogix 500
Max. Current per point	2.5 A
Operating Voltage Range	5-265V AC; 5-125V DC
Part Number/Catalog No.	1762-OW16
Relay Contact Voltage Ratings	24-125 VDC;120-240VAC

Allen-Bradley

1762-OW16

Rate this product

PLCs MicroLogix 1200

The Allen-Bradley 1762-OW16 is a MicroLogix series relay output module featuring 16 AC/DC normally open relays, compatible with MicroLogix 1100, 1200, and 1400 controllers. Offering two isolated groups with eight channels each, it supports a relay contact voltage rating of 24-125 VDC and 120-240 VAC, with an operating range of 5-265V AC and 5-125V DC.

PDF

We currently only collect tax from customers in the state of North Carolina. If you are exempt on your purchase, please email your Sales Tax & Use Exemption Form to sales@replacenc.com.
If you are checking out via a quote we send you, there is an option to upload your form at the time of purchase.

If you have already placed an order, please send us your form and we can refund the charged taxes.

Overview of Allen-Bradley 1762-OW16

The Allen-Bradley 1762-OW16 is a compact I/O module designed for use within the MicroLogix 1200 and MicroLogix 1400 controller series. This module is specifically engineered for controlling output operations and is part of the larger Allen-Bradley MicroLogix family of controllers. Equipped with 16 relay outputs, it is an ideal solution for applications that require the direct control of physical devices such as motors, lights, or solenoids.

Technical Specifications

The 1762-OW16 module has 16 Form A relay outputs, which are singly isolated from each other. Each output can handle a current of up to 2 Amps at 30 Volts DC or 5 Amps at 240 Volts AC, providing the flexibility needed to manage a diverse range of equipment. It can be easily installed onto a DIN rail or panel, ensuring a secure fit into a wide variety of industrial environments. The module also comes with removable terminal blocks that simplify the wiring process, making maintenance and module replacement straightforward.

Integration and Compatibility

As part of the MicroLogix controller platform, the 1762-OW16 module seamlessly integrates with other I/O modules and devices within the same family. This integration simplifies expansion and system configuration. It is designed to work in conjunction with the MicroLogix 1200 and 1400 series PLCs and is configured using the RSLogix 500 programming software, ensuring easy setup and programming for users familiar with the Allen-Bradley control systems.

Durability and Operational Considerations

The 1762-OW16 module boasts a sturdy design built to withstand the challenging conditions found in industrial environments. It offers reliable performance under a wide temperature range, ensuring consistent operation in both cold and hot settings. Furthermore, its electrical isolation between the outputs improves protection from transients and electrical noise, which is critical in maintaining the integrity of control systems.

Applications and Use Cases

Allen-Bradley's 1762-OW16 module is widely used in applications that demand reliable output switching capabilities. It is suitable for a variety of industries including manufacturing, automotive, food and beverage, and packaging. It is particularly helpful in scenarios where discrete control of devices is necessary, such as assembly lines, material handling systems, and process control applications. The module’s durability and reliability make it a preferred choice for engineers and technicians in these sectors.
