| UPC | 10612598205896 |
| Brand | Allen-Bradley |
| Series | A and B |
| Humidity | 5% to 95% non-condensing |
| Mounting | DIN Rail; Panel |
| Software | RSLogix5000 |
| Enclosure | Open |
| Dimensions | 118mm (height) x 87mm (depth) x 50mm (width) height including mounting tabs is 138mm 4.65in (height) x 3.43in (depth) x 1.97in (width) height including mounting tabs is 5.43in |
| Indicators | Module Status: red/grnNetwork status - red/grnI/O status- red/grn Diagnostic status- red/grn |
| Module Type | DeviceNet Adapter Module |
| Manufacturer | Rockwell Automation |
| Product Line | CompactLogix |
| Shipping Weight | 2 pounds |
| Backplane Current | Series A: 450mA at 5V dc (2.25W)Series B: 500mA at 5V dc (2. 5W) |
| Isolation Voltage | 30 Volts Continuous |
| Power Consumption | 33.6 Watts |
| Power Dissipation | 7.5 Watts |
| Communication Port | One (1) DeviceNet |
| Data Transfer speed | 125k bit/s 250k bit/s 500k bit/s |
| Product Description | 1769 CompactLogix DeviceNet Scanner |
| Shipping Dimensions | 8x8x5 inches |
| Storage Temperature | -40°F to +185°F (-40°C to +85°C) |
| Agency Certification | UL; CE; DeviceNet Foundation |
| Programming software | RSnetworx for DeviceNet |
| Operating Temperature | 32°F to 140°F (0°C to 60°C) |
| Part Number/Catalog No. | 1769-ADN |
| Power Supply Distance Rating | Series A: 4; Series B: 5 |
Does the Allen-Bradley 1769-ADN come with a warranty?
Yes. The 1769-ADN is backed by our 24-Month Replace Industrial Warranty, with no rush fees or hidden warranty charges. If a unit fails under normal use within the warranty period, we repair or replace it.
Is this 1769-ADN a genuine Allen-Bradley part?
The 1769-ADN is sourced and verified independently. Replace Industrial, LLC is not a Rockwell Automation Authorized Distributor, and all warranties are provided directly by Replace Industrial.
Is the Allen-Bradley 1769-ADN new or used?
We offer the 1769-ADN in multiple conditions, from unused surplus to professionally reconditioned units. Every option is sourced and verified independently and covered by our 2-year replacement warranty.
What are the key ratings of the 1769-ADN?
The 1769-ADN is rated at 33.6 Watts and operates across 32°F to 140°F (0°C to 60°C).
What is the Allen-Bradley 1769-ADN?
The 1769-ADN is an Allen-Bradley CompactLogix 1769 DeviceNet Adapter Module.
1769-ADN
The Allen-Bradley 1769-ADN CompactLogix PLC is a DeviceNet Adapter Module designed by Rockwell Automation for seamless factory network integration. It supports data transfer speeds up to 500k bit/s, operates within a temperature range of 0°C to 60°C, and mounts easily on DIN rails or panels. The module ensures efficient and reliable communication within sophisticated industrial systems.
