| UPC | 10612598287243 |
| Brand | Allen-Bradley |
| Series | A and B |
| UNSPSC | 32151705 |
| Humidity | 5% to 95% non-condensing |
| Mounting | DIN Rail; Panel |
| Software | RSLogix5000 |
| Wire Type | Copper at 90 degrees Celsius |
| Dimensions | 118 mm (height) x 87 mm (depth) x 35 mm (width) height including mounting tabs is 138 mm 4.65 in. (height) x 3.43 in (depth) x 1.38 in (width) height including mounting tabs is 5.43 in. |
| Indicators | Module Status: red/grnNetwork status - red/grnI/O status- red/grn Diagnostic status- red/grn |
| Description | DeviceNet Scanner |
| Module Type | DeviceNet Communication Module |
| Manufacturer | Rockwell Automation |
| No. of nodes | 63 |
| Product Line | CompactLogix |
| Product Type | Communication Module |
| Shipping Weight | 2 pounds |
| Solid Wire Size | 22 to 14 AWG |
| Heat Dissipation | 440 mA at 5 Volts DC/2.2 Watts |
| Backplane Current | Series A: 450mA at 5V dc (2.25W)Series B: 500mA at 5V dc (2. 5W) |
| Communication Port | One (1) DeviceNet |
| Stranded Wire Size | 22 to 16 AWG |
| Data Transfer speed | 125k bit/s 250k bit/s 500k bit/s |
| Shipping Dimensions | 8 x 8 x 5 inches |
| Storage Temperature | -40°F to +185°F (-40°C to +85°C) |
| Agency Certification | UL; CE; DeviceNet Foundation |
| Programming software | RSLinx. RSnetworx for DeviceNet, RSLogix500, RSLogix 5000 |
| Operating Temperature | 32°F to 140°F (0°C to 60°C) |
| Part Number/Catalog No. | 1769-SDN |
| Power Supply Distance Rating | Series A: 4; Series B: 5 |
Does the Allen-Bradley 1769-SDN come with a warranty?
Yes. The 1769-SDN is backed by our 24-Month Replace Industrial Warranty, with no rush fees or hidden warranty charges. If a unit fails under normal use within the warranty period, we repair or replace it.
Is this 1769-SDN a genuine Allen-Bradley part?
The 1769-SDN is sourced and verified independently. Replace Industrial, LLC is not a Rockwell Automation Authorized Distributor, and all warranties are provided directly by Replace Industrial.
Is the Allen-Bradley 1769-SDN new or used?
We offer the 1769-SDN in multiple conditions, from unused surplus to professionally reconditioned units. Every option is sourced and verified independently and covered by our 2-year replacement warranty.
What are the key ratings of the 1769-SDN?
The 1769-SDN operates across 32°F to 140°F (0°C to 60°C).
What is the Allen-Bradley 1769-SDN?
The 1769-SDN is an Allen-Bradley CompactLogix 1769 DeviceNet Communication Module.
1769-SDN
The Allen-Bradley 1769-SDN CompactLogix is a DeviceNet Scanner module by Rockwell Automation designed for communication in industrial settings. This module facilitates data transfer at speeds up to 500k bit/s, supports 63 nodes, and integrates with RSLogix5000 software. It's DIN rail mountable, operates between 0-60°C, and ensures reliable network status indicators.
