| EMC filter | Level 3 EMC filter |
| Option card | Communication card APOGEE FLN Communication card BACnet Communication card CC-Link Controller inside programmable card Communication card DeviceNet Communication card EtherNet/IP Communication card Fipio I/O extension card Communication card Interbus-S Communication card LonWorks Communication card METASYS N2 Communication card Modbus Plus Communication card Modbus TCP Communication card Modbus/Uni-Telway Multi-pump card Communication card Profibus DP Communication card Profibus DP V1 |
| Line current | 42 A 480 V 3 phase 22 kW / 30 hp 50 A 380 V 3 phase 22 kW / 30 hp |
| Apparent power | 32.9 kVA 380 V 3 phase 22 kW / 30 hp |
| Assembly style | With heat sink |
| Component name | ATV61 |
| Motor power kW | 22 kW, 3 phase 380...480 V |
| Range of Product | Altivar 61 |
| Switching frequency | 1...16 kHz adjustable 12...16 kHz with derating factor |
| Type of polarization | No impedance Modbus |
| power supply voltage | 380...480 V - 15...10 % |
| supply number of phases | 3 phase |
| Maximum transient current | 57.6 A 60 s, 3 phase |
| Product or Component Type | Variable speed drive |
| Maximum Horse Power Rating | 30 hp, 3 phase 380...480 V |
| asynchronous motor control | Voltage/frequency ratio, 5 points Voltage/frequency ratio, 2 points Flux vector control without sensor, standard Voltage/frequency ratio - Energy Saving, quadratic U/f |
| Nominal switching frequency | 12 kHz |
| communication port protocol | Modbus CANopen |
| Product Specific Application | Pumping and ventilation machine |
| maximum prospective line Isc | 22 kA 3 phase |
| Synchronous motor control profile | Vector control without sensor, standard |
Does the Schneider Electric ATV61HD22N4 come with a warranty?
Yes. The ATV61HD22N4 is backed by our 24-Month Replace Industrial Warranty, with no rush fees or hidden warranty charges. If a unit fails under normal use within the warranty period, we repair or replace it.
Is this ATV61HD22N4 a genuine Schneider Electric part?
The ATV61HD22N4 is sourced and verified independently. Replace Industrial is not an authorized distributor, affiliate, or representative of Schneider Electric, and all warranties are provided directly by Replace Industrial.
Is the Schneider Electric ATV61HD22N4 new or used?
We offer the ATV61HD22N4 in multiple conditions, from unused surplus to professionally reconditioned units. Every option is sourced and verified independently and covered by our 2-year replacement warranty.
What are the key ratings of the ATV61HD22N4?
The ATV61HD22N4 is rated at 22 kW, 3 phase 380...480 V, runs on 380...480 V - 15...10 %, and communicates over Modbus CANopen.
What is the Schneider Electric ATV61HD22N4?
The ATV61HD22N4 is a Schneider Electric ATV 61 Variable speed drive.
ATV61HD22N4
The ATV61HD22N4 is a 22 kW, 30 hp variable speed drive by Altivar 61, designed for 3-phase 480V power supply, with EMC filter level 3 and an IP20 protection rating. It's suitable for pumping and ventilation applications and features a graphical terminal for easy programming and monitoring.
