| EMC filter | Level 3 EMC filter |
| Option card | Communication card APOGEE FLN Communication card BACnet Communication card CC-Link Controller inside programmable card Communication card DeviceNet Communication card EtherNet/IP Communication card Fipio I/O extension card Communication card Interbus-S Communication card LonWorks Communication card METASYS N2 Communication card Modbus Plus Communication card Modbus TCP Communication card Modbus/Uni-Telway Multi-pump card Communication card Profibus DP Communication card Profibus DP V1 |
| Line current | 56 A 480 V 3 phase 30 kW / 40 hp 66 A 380 V 3 phase 30 kW / 40 hp |
| Apparent power | 43.4 kVA 380 V 3 phase 30 kW / 40 hp |
| Assembly style | With heat sink |
| Component name | ATV61 |
| Motor power kW | 30 kW, 3 phase 380...480 V |
| Range of Product | Altivar 61 |
| Switching frequency | 1...16 kHz adjustable 12...16 kHz with derating factor |
| Type of polarization | No impedance Modbus |
| power supply voltage | 380...480 V - 15...10 % |
| supply number of phases | 3 phase |
| Maximum transient current | 79.2 A 60 s, 3 phase |
| Product or Component Type | Variable speed drive |
| Maximum Horse Power Rating | 40 hp, 3 phase 380...480 V |
| asynchronous motor control | Voltage/frequency ratio, 5 points Voltage/frequency ratio - Energy Saving, quadratic U/f Voltage/frequency ratio, 2 points Flux vector control without sensor, standard |
| Nominal switching frequency | 12 kHz |
| communication port protocol | CANopen Modbus |
| Product Specific Application | Pumping and ventilation machine |
| maximum prospective line Isc | 22 kA 3 phase |
| Synchronous motor control profile | Vector control without sensor, standard |
Does the Schneider Electric ATV61HD30N4 come with a warranty?
Yes. The ATV61HD30N4 is backed by our 24-Month Replace Industrial Warranty, with no rush fees or hidden warranty charges. If a unit fails under normal use within the warranty period, we repair or replace it.
Is this ATV61HD30N4 a genuine Schneider Electric part?
The ATV61HD30N4 is sourced and verified independently. Replace Industrial is not an authorized distributor, affiliate, or representative of Schneider Electric, and all warranties are provided directly by Replace Industrial.
Is the Schneider Electric ATV61HD30N4 new or used?
We offer the ATV61HD30N4 in multiple conditions, from unused surplus to professionally reconditioned units. Every option is sourced and verified independently and covered by our 2-year replacement warranty.
What are the key ratings of the ATV61HD30N4?
The ATV61HD30N4 is rated at 30 kW, 3 phase 380...480 V, runs on 380...480 V - 15...10 %, and communicates over CANopen Modbus.
What is the Schneider Electric ATV61HD30N4?
The ATV61HD30N4 is a Schneider Electric ATV 61 Variable speed drive.
ATV61HD30N4
The ATV61HD30N4 is a 40 HP Altivar 61 variable speed drive designed for 3-phase motors with a power supply of 380 to 480 V. It features an EMC IP20 filter, graphic terminal, and is suited for pumping and ventilation applications, offering efficient control and communication options for industrial settings.
