| Phase | 3 phase |
| EMC filter | Integrated |
| Line current | 11.5 A 480 V 3 phase 4 kW / 5 hp 14.1 A 380 V 3 phase 4 kW / 5 hp |
| Apparent power | 9.3 kVA 380 V 3 phase 4 kW / 5 hp |
| Assembly style | With heat sink |
| Component name | ATV71 |
| Motor power kW | 4 kW, 3 phase 380...480 V |
| Output frequency | 0.1…599 Hz |
| Range of Product | Altivar 71 |
| Switching frequency | 1...16 kHz adjustable 4...16 kHz with derating factor |
| Prospective line Isc | 5 kA 3 phase |
| Type of polarization | No impedance Modbus |
| power supply voltage | 380...480 V - 15...10 % |
| Nominal output current | 10.5 A 4 kHz 380 V 3 phase 4 kW / 5 hp 7.6 A 4 kHz 460 V 3 phase 4 kW / 5 hp |
| Maximum transient current | 15.8 A 60 s 3 phase 4 kW / 5 hp 17.3 A 2 s 3 phase 4 kW / 5 hp |
| Product or Component Type | Variable speed drive |
| Maximum Horse Power Rating | 5 hp, 3 phase 380...480 V |
| Maximum motor cable length | 164.04 ft (50 m) shielded cable 328.08 ft (100 m) unshielded cable |
| Nominal switching frequency | 4 kHz |
| Product Specific Application | Complex, high-power machines |
| Asynchronous motor control profile | Flux vector control (FVC) with sensor (current vector) ENA (Energy adaptation) system for unbalanced loads Sensorless flux vector control (SFVC) (voltage or current vector) Voltage/frequency ratio (2 or 5 points) |
Does the Schneider Electric ATV71HU40N4 come with a warranty?
Yes. The ATV71HU40N4 is backed by our 24-Month Replace Industrial Warranty, with no rush fees or hidden warranty charges. If a unit fails under normal use within the warranty period, we repair or replace it.
Is this ATV71HU40N4 a genuine Schneider Electric part?
The ATV71HU40N4 is sourced and verified independently. Replace Industrial is not an authorized distributor, affiliate, or representative of Schneider Electric, and all warranties are provided directly by Replace Industrial.
Is the Schneider Electric ATV71HU40N4 new or used?
We offer the ATV71HU40N4 in multiple conditions, from unused surplus to professionally reconditioned units. Every option is sourced and verified independently and covered by our 2-year replacement warranty.
What are the key ratings of the ATV71HU40N4?
The ATV71HU40N4 is rated at 4 kW, 3 phase 380...480 V, runs on 380...480 V - 15...10 %, and draws 10.5 A 4 kHz 380 V 3 phase 4 kW / 5 hp 7.6 A 4 kHz 460 V 3 phase 4 kW / 5 hp.
What is the Schneider Electric ATV71HU40N4?
The ATV71HU40N4 is a Schneider Electric ATV 71 Variable speed drive.
ATV71HU40N4
The ATV71HU40N4 is a robust 4kW-5HP 480V variable speed drive (VSD) from the Altivar 71 range, designed for complex, high-power machines. This three-phase unit features an integrated EMC filter, a graphic terminal for easy interfacing, and supports various motor control profiles, ensuring optimized performance for diverse applications.
All products are covered by our 2-Year (24-Month) Replace Industrial Warranty. If a unit is found defective under normal use within the warranty period, we repair or replace it at no additional cost, and a unit may be returned for a full refund within 30 days if returned in the same condition it was sent.
Replace Industrial is an independent distributor and does not convey the manufacturer's warranty; all warranties are provided by Replace Industrial alone. Read the full warranty policy
