| Phase | 3 phase |
| EMC filter | Integrated |
| Line current | 7.1 A 480 V 3 phase 2.2 kW / 3 hp 8.2 A 380 V 3 phase 2.2 kW / 3 hp |
| Apparent power | 5.4 kVA 380 V 3 phase 2.2 kW / 3 hp |
| Assembly style | With heat sink |
| Component name | ATV71 |
| Motor power kW | 2.2 kW, 3 phase 380...480 V |
| Output frequency | 0.1…599 Hz |
| Range of Product | Altivar 71 |
| Switching frequency | 1...16 kHz adjustable 4...16 kHz with derating factor |
| Prospective line Isc | 5 kA 3 phase |
| Type of polarization | No impedance Modbus |
| power supply voltage | 380...480 V - 15...10 % |
| Nominal output current | 4.8 A 4 kHz 460 V 3 phase 2.2 kW / 3 hp 5.8 A 4 kHz 380 V 3 phase 2.2 kW / 3 hp |
| Maximum transient current | 8.7 A 60 s 3 phase 2.2 kW / 3 hp 9.6 A 2 s 3 phase 2.2 kW / 3 hp |
| Product or Component Type | Variable speed drive |
| Maximum Horse Power Rating | 3 hp, 3 phase 380...480 V |
| Maximum motor cable length | 164.04 ft (50 m) shielded cable 328.08 ft (100 m) unshielded cable |
| Nominal switching frequency | 4 kHz |
| Product Specific Application | Complex, high-power machines |
| Asynchronous motor control profile | Sensorless flux vector control (SFVC) (voltage or current vector) Flux vector control (FVC) with sensor (current vector) Voltage/frequency ratio (2 or 5 points) ENA (Energy adaptation) system for unbalanced loads |
Does the Schneider Electric ATV71HU22N4 come with a warranty?
Yes. The ATV71HU22N4 is backed by our 24-Month Replace Industrial Warranty, with no rush fees or hidden warranty charges. If a unit fails under normal use within the warranty period, we repair or replace it.
Is this ATV71HU22N4 a genuine Schneider Electric part?
The ATV71HU22N4 is sourced and verified independently. Replace Industrial is not an authorized distributor, affiliate, or representative of Schneider Electric, and all warranties are provided directly by Replace Industrial.
Is the Schneider Electric ATV71HU22N4 new or used?
We offer the ATV71HU22N4 in multiple conditions, from unused surplus to professionally reconditioned units. Every option is sourced and verified independently and covered by our 2-year replacement warranty.
What are the key ratings of the ATV71HU22N4?
The ATV71HU22N4 is rated at 2.2 kW, 3 phase 380...480 V, runs on 380...480 V - 15...10 %, and draws 4.8 A 4 kHz 460 V 3 phase 2.2 kW / 3 hp 5.8 A 4 kHz 380 V 3 phase 2.2 kW / 3 hp.
What is the Schneider Electric ATV71HU22N4?
The ATV71HU22N4 is a Schneider Electric ATV 71 Variable speed drive.
ATV71HU22N4
The ATV71HU22N4 is a 2.2kW, 3HP variable speed drive designed for complex machinery, featuring a 480V power supply, integrated EMC filter, and graphic terminal. It supports up to 100 meters of unshielded motor cable and includes a heat sink for durability, making it suitable for demanding industrial environments.
