Is the Allen-Bradley 1769-AENTR new or used?

We offer the 1769-AENTR in multiple conditions, from unused surplus to professionally reconditioned units. Every option is sourced and verified independently and covered by our 2-year replacement warranty.

What is the Allen-Bradley 1769-AENTR?

The 1769-AENTR is an Allen-Bradley CompactLogix 1769 EtherNet/IP Adapter.

How fast does the 1769-AENTR ship?

In-stock orders for the 1769-AENTR ship the same day when placed before our daily cutoff. Expedited and same-day air options are available if you are facing downtime, with no rush fees. Our team is based in Raleigh, North Carolina.

Brand	Allen-Bradley
Manufacturer	Rockwell Automation
Product Line	CompactLogix
Product Type	EtherNet/IP Adapter
Logix Resources	128 EtherNet/IP connections
Backplane Current	500 mA at 5V
Communication Rate	10/100 Mbps
TCP/IP Connections	96
Part Number/Catalog No.	1769-AENTR
Power Supply Distance Rating	5

Allen-Bradley

1769-AENTR

Rate this product

Ready to ShipPLCs CompactLogix 1769

The Allen-Bradley 1769-AENTR, part of the CompactLogix lineup by Rockwell Automation, is an EtherNet/IP Adapter facilitating 10/100 Mbps communication. It supports 128 EtherNet/IP and 96 TCP/IP connections, operates on a backplane current of 500 mA at 5V, and has a power supply distance rating of 5.

PDF

We currently only collect tax from customers in the state of North Carolina. If you are exempt on your purchase, please email your Sales Tax & Use Exemption Form to sales@replacenc.com.
If you are checking out via a quote we send you, there is an option to upload your form at the time of purchase.

If you have already placed an order, please send us your form and we can refund the charged taxes.

Overview of Allen-Bradley 1769-AENTR

The Allen-Bradley 1769-AENTR is an EtherNet/IP adapter module that belongs to the CompactLogix 5370 series of controllers. This adapter is designed to provide communication capabilities for CompactLogix 1769-LxxERMs and 1769-LxxERMK controllers, enabling them to interface with other Ethernet/IP devices. It allows for the establishment of a robust network system that facilitates data exchange across various platforms and devices.

Networking Capabilities

The 1769-AENTR module supports dual-port Ethernet connectivity, which enhances network resiliency through a Device Level Ring (DLR) network topology. This feature aids in maintaining network continuity even in the case of a link failure, thus improving overall system reliability. Additionally, the 1769-AENTR allows for linear and star network configurations, broadening its applicability in complex network layouts.

Performance and Specifications

This adapter module is known for its high performance, providing data transfer rates of up to 100 Mbps. Its compact size makes it ideal for space-constrained applications, and it can operate in a wide range of industrial environments with a temperature range between -20 to 70 degrees Celsius. The module also includes diagnostic indicators giving real-time feedback on the operating status and network health.

Compatibility and Integration

Allen-Bradley's 1769-AENTR is designed to seamlessly integrate with other modules in the CompactLogix family and can be connected to the backplane of a 1769 I/O chassis. The integration process requires minimal configuration, and the module supports the use of RSLogix 5000 or Studio 5000 Logix Designer software, simplifying setup and programming tasks for automation professionals.

Application and Industry Usage

Due to its robust networking and communication capabilities, the Allen-Bradley 176_pressed2-AENTR is highly suitable for a wide array of applications, including but not limited to manufacturing processes, packaging equipment, material handling, and automated assembly operations. Its wide adoption across various industries, including automotive, pharmaceutical, and food and beverage, underlines its reliability and effectiveness in different automation settings.
