Is the Allen-Bradley 1769-OF4CI new or used?

We offer the 1769-OF4CI in multiple conditions, from unused surplus to professionally reconditioned units. Every option is sourced and verified independently and covered by our 2-year replacement warranty.

What is the Allen-Bradley 1769-OF4CI?

The 1769-OF4CI is an Allen-Bradley CompactLogix 1769 Analog Output Module.

How fast does the 1769-OF4CI ship?

In-stock orders for the 1769-OF4CI ship the same day when placed before our daily cutoff. Expedited and same-day air options are available if you are facing downtime, with no rush fees. Our team is based in Raleigh, North Carolina.

UPC	10781180908658
Brand	Allen-Bradley
Series	A and B
UNSPSC	32151705
Software	RSLogix5000
Wire Type	Copper-90 AWG
Slot width	1
Calibration	None required (guaranteed by hardware design)
Module Type	Analog Output Module
Manufacturer	Industrial Automation / Allen-Bradley
Power Supply	1769-PA2, 1769-PB2, 1769-PA4, 1769-PB4
Analog Ranges	Current: 0 to 20 mA, 4 to 20 mA
No. of outputs	Four (4) Differential; Individually isolated
Product Family	Compact I/O
Conversion rate	110 ms
Module location	DIN rail or panel mount
Shipping Weight	2 pounds
Solid Wire Size	22 to 14 AWG
Field Calibration	None Required
Recommended cable	Belden 8761 (shielded)
Analog data format	Raw / Proportional data, Engineering unit, Scaled for PID and Percent full range.
Digital resolution	16 bits (unipolar) +4 to +20 mA: 15.59 bits, 0.323 ÂµA/bit 0 to +20 mA: 15.91 bits, 0.323 ÂµA/bit
Stranded Wire Size	22 to 16 AWG
Communication Cable	4 Point
Shipping Dimensions	8 x 8 x 5 inches
Programming software	RSLogix 500; RSLogix 5000 / Studio 5000 Logix Designer
Compatible controllers	MicroLogix 1500; CompactLogix controllers
Part Number/Catalog No.	1769-OF4CI
Full scale analog ranges	Current: 0 - 21 mA, 3.2 - 21 mA
Power Supply Distance Rating	8
Replacement Door Part Number	1769-RD
Non-linearity (in percent full scale)	Â±0.05%

Allen-Bradley

1769-OF4CI

Rate this product

PLCs CompactLogix 1769

The Allen-Bradley 1769-OF4CI is a Compact I/O Analog Output Module with four individually isolated differential outputs. Designed for industrial automation, it requires no field calibration and boasts a 16-bit resolution. Compatible with MicroLogix 1500 and CompactLogix controllers, this module is easily integrated with RSLogix software, ensuring efficient setup and reliable performance.

PDF

We currently only collect tax from customers in the state of North Carolina. If you are exempt on your purchase, please email your Sales Tax & Use Exemption Form to sales@replacenc.com.
If you are checking out via a quote we send you, there is an option to upload your form at the time of purchase.

If you have already placed an order, please send us your form and we can refund the charged taxes.

Overview of Allen-Bradley 1769-OF4CI

The Allen-Bradley 1769-OF4CI is an analog output module designed to be part of the CompactLogix and MicroLogix 1500 system platforms. It is part of the 1769 Compact I/O series, which provides compact, flexible solutions for distributed I/O requirements. This module is specifically engineered to convert digital signals from the processor to analog signals for controlling various industrial devices such as actuators and drives.

Technical Specifications

The 1769-OF4CI module features four channels of current and voltage outputs, with individually configurable channels. Each channel can be set up to produce an analog output in the range of 0-20mA, 4-20mA, or 0-10V, 0-5V, and ±10V, catering to different control application needs. It also offers an isolated channel to channel design to reduce electrical noise and provide robust performance in harsh industrial environments.

Programming and Configuration

Programming the 1769-OF4CI module is accomplished using RSLogix 5000 or RSLogix Studio 5000 software, which is part of the Rockwell Automation Integrated Architecture. The software allows users to easily configure the module’s parameters and wiring settings. Additionally, the module can be used in conjunction with Allen-Bradley's FactoryTalk View software for simplified monitoring and diagnostics.

Installation and Compatibility

Installation is made simple with the 1769-OF4CI's compact design, fitting within a standard 1769 I/O chassis. For power supply, the module works efficiently with either 24V DC or a bus power from the I/O chassis. It's crucial to ensure compatibility with the existing CompactLogix or MicroLogix system to guarantee proper functioning. This module can also be seamlessly integrated with other modules in the Compact I/O series to expand system capabilities.

Safety and Quality Assurance

The 1769-OF4CI is designed with safety and reliability in mind, complying with global industrial standards. Allen-Bradley ensures the quality of its modules through rigorous testing and certification processes, which include meeting UL, CE, C-TICK, and EX hazardous location ratings. Users can expect a durable and long-lasting solution when choosing the 1769-OF4CI for their automated industrial applications.
